SIP T1 Timeout
T1 is an estimate of the round-trip time between the client and server transactions.
If the network latency is high, select larger value for more reliable usage.
SIP T2 Interval
Maximum retransmission interval for non-INVITE requests and INVITE responses.
DTMF Payload Type
Sets the payload type for DTMF using RFC2833.
Preferred DTMF method
The HT502 supports up to 3 different DTMF methods including in-audio, via RTP
(RFC2833) and via Sip Info. The user can configure DTMF method in a priority list.
Disable DTMF
Negotiation
Default is No. If set to yes, use above DTMF order without negotiation
DTMF via RFC2833
Send DTMF via RTP (According to RFC 2833).
DTMF via SIP INFO
Send DTMF via SIP INFO message.
Send Flash Event
Default is No. If set to yes, flash will be sent as DTMF event.
Enable Call Features Default is Yes. (If Yes, call features using star codes will be supported locally)
Offhook Auto-Dial This parameter allows users to configure a User ID or extension number that is
automatically dialed when off-hook. Only the user part of a SIP address needs is
entered here. The HT502 will automatically append the “@” and the host portion of the
corresponding SIP address.
Proxy-Require
SIP Extension to notify SIP server that the unit is behind the NAT/Firewall.
Use NAT IP
NAT IP address used in SIP/SDP message. Default is blank.
Distinctive Ring Tone
Custom Ring Tone 1 to 3 with associate Caller ID: when selected, if Caller ID is
configured, then the device will ONLY uses this ring tone when the incoming call is
from the Caller ID. System Ring Tone is used for all other calls. When selected but no
Caller ID is configured, the selected ring tone will be used for all incoming calls.
Distinctive ring tones can be configured not only for matching a whole number, but also
for matching prefixes. In this case symbol * (star) will be used.
For example:
if configured as *617, Ring Tone 1 will be used in case of call arrived from the area
code 617. Any other incoming call will ring using cadence defined in parameter System
Ring Cadence located under Advanced Settings Configuration page.
Note: If server supports Alert-Info header and standard ring tone set (Bellcore) or
distinctive ring tone 1-10 is specified, then the ring tone in the Alert-Info header from
server will be used. Bellcore rings and tones are independent from custom ring tones.
The custom ring tones can also be specified by alert-info header, for example
Alert-Info: <http://127.0.0.1>;info=ring5
Disable Call Waiting
Default is No. If set to YES Call Waiting indication information will not be provided to
analog phone connected to this FXS port.
Disable Call-Waiting
Caller ID
Default is No. If set to YES Call Waiting caller ID will not be provided to analog phone
connected to this FXS port.
Disable Call Waiting
Tone
Default is No. This is to disable the stutter Call Waiting Tone when a Call Waiting
information arrives. The CWCID information will still be displayed.
Disable Reminder Ring
for On-Hold Call
Default is No. Do not play the reminder ring when this is set to Yes.
Disable Visual MWI If set to “Yes”, the MWI information will not be transferred to the analog phone
connected to the FXS port.
Ring Timeout
Incoming call will stop ringing when not picked up given a specific period of time.
Delayed Call Forward
Wait Time
Default value is 20 seconds. In case this feature activated using * codes (*92 code), the
call will be forwarded after this preconfigured amount of time.
No Key Entry Timeout Default is 4 seconds. Dialing process is completed and outgoing call is initiated if no
key entry occurs during this preconfigured interval.
Early Dial Default is No. Use only if proxy supports 484 response. This parameter controls
whether the phone will send an early INVITE each time a key is pressed when a user
dials a number. If set to “Yes”, an INVITE is sent using the dial-number collected thus
far; Otherwise, no INVITE is sent until the “(Re-)Dial” button is pressed or after about 5
