IP Phone User's Manual

GXV3140 USER MANUAL www.grandstream.com
SOFTWARE VERSION 1.0.0.44 [e-mail]
activate voice mail or other applications provided by their service provider, the *
should be predefined inside the dial plan feature. An example dial plan will be:
{ *x+ } which allows the user to dial * followed by any length of numbers.
Early Dial The default setting is NO. Only use this if the proxy supports the 484 response.
Refer to Use Target
Contact
The default is NO. If set to YES, then for Attended Transfer, the “Refer-To”
header uses the transferred target’s contact header information.
Auto Answer The default setting is NO. If it is set to YES, the GXV3140 will play a “beep”
sound and answer the phone automatically on the speaker.
Send Anonymous If set to YES, the “From” header in the outgoing SIP messages will be set to
anonymous to block the caller ID from displaying. The default setting is NO.
Anonymous Call
Rejection
The default setting is NO；If set to YES，any anonymous call will be rejected（with
486Busy message）
Account Ring Tone There are four ring tones to choose from:
1 system ring tone: After selecting this, all calls will have the same ring tone.
3 custom ring tones: The phone will have different ring tones according to the
caller.
Special Feature The default setting is Standard; different features can be selected depending on
the user needs.
Enable Call features The default is set to YES. If set to NO, the call features are disabled.
Call Forward
Unconditional
Sets the number to forward to unconditionally.
Call Forward When
Busy
Sets the number to forward to when busy.
Call Forward When No
Answer
Sets the number to forward to when no answer.
Delayed Call Forward
Wait Time (s)
The wait time before transferring the call to another extension or to voicemail;
the default setting is 20 seconds.
No Key Entry Timeout
(s)
Defines the time out duration on no key entry.
Default setting is 4 seconds.
Use # as Dial Key Selects whether or not # is used as Send.
