SIP ACCOUNT CONFIGURATION PAGE DEFINITIONS
The GXV3140 has three lines that can configure independent SIP accounts. Every SIP account has an
individual configuration page.
Account/Generic Settings
Account Active Select YES to enable and use the Line.
Account Name The Account name for the user that is displayed on the LCD screen.
SIP Server The IP address of the SIP server or the given domain name of the VoIP service
provider.
SIP User ID User account information provided by the VoIP service provider; normally similar
to a telephone number or an actual telephone number.
Authenticate ID The authenticate ID for the SIP user. It can differ or be the same as the SIP user
ID.
Authenticate password The password that the GXV uses to authenticate with the ITSP (SIP) server.
After it is saved, this will appear as blank for security reasons. The maximum
length is 25 characters.
Voice Mail UserID When this is configured, the user can dial to the voicemail server using the
MESSAGE button. This ID is normally the feature code for Voice Mail.
Name The Caller ID that will be displayed for the account.
User ID is phone
number:
If the Video phone has an assigned PSTN number, this field should be set to
“YES”. Otherwise, set it to “NO”. If “YES” is set, a “user=phone” parameter will
be attached to the “From header” in the SIP request to indicate the E.164
number.
Account/Network Settings
Outbound Proxy IP address or Domain name of the Outbound Proxy, or Media Gateway, or
Session Border Controller. Used by the GXV3140 for firewall or NAT penetration
in different network environments. If a symmetric NAT is detected, STUN will not
work and ONLY an Outbound Proxy will work.
DNS Mode The default is set to A Record. If the user wishes to locate the server by DNS
SRV, the user may select SRV or NATPTR/SRV.
NAT Traversal This setting decides whether the NAT traversal mechanism is activated. If it is set
to “Yes” and STUN server is configured, the GXV3140 will route according the
STUN server.
