IP Phone User's Manual

GXV3140 USER MANUAL www.grandstream.com
SOFTWARE VERSION 1.0.0.44 [e-mail]
Config File Postfix This field enables your ITSP to lock configuration updates. If configured, only the
configuration file with the matching encrypted postfix will be downloaded and
flashed into the phone.
DHCP Option 66
override Server
The Default setting is YES. If DHCP option 66 is enabled on the LAN side, the
TFTP server can be redirected. Please be very careful when configuring this as
the redirection could break the phone if this happens during the firmware
upgrade.
Automatic Upgrade The default value is NO. Choose “YES” to enable automatic HTTP upgrade and
provisioning.
Automatic Upgrade
Interval
Defines the interval (in minutes) to check the HTTP/TFTP server for firmware
upgrades or configuration files changes.
Automatic Upgrade
Rule
Defines the rules for automatic upgrade: Always Check, when F/W suffix/prefix
changes, Skip the Firmware Check.
Authenticate Conf File Authenticate configuration file before acceptance. The Default setting is NO.
Factory Reset Press the RESET button to factory reset the phone.
Maintenance/Syslog
Syslog Server The URL/IP address for the syslog server.
Syslog Level Select the level of logging for syslog. The default setting is NONE.
There are 4 levels: INFO, DEBUG, ERROR and WARNING.
Maintenance/Capture Packet
Capture Trace Press START to start capturing a trace. Press STOP to abort the capture
process.
View Trace Press LIST to view the list of captured traces. It will show the time the trace was
captured. Click on the name to download and view the trace.
Enable Application
Debug
When set to YES, the trace captured will contain debug messages.
The default setting is NO.
Maintenance/Language
Language Selects the language setting for the phone.
