Base in LDAP configuration will be used if the Description field is left
blank. Enter the LDAP Name/Number filter in the Value field.
For example:
If users set MPK 1 as “LDAP Search” for “Account 1”, and set filters:
Description -> ou=video,ou=SZ,dc=grandstream,dc=com
Value -> sn=Li
Since the Base for LDAP server configuration is
“dc=grandstream,dc=com”, “ou=video,ou=SZ” is added to narrow the
LDAP search scope. “sn=Li” is the example to filter the last name.
 Call Log
Select Account and enter account number in the Value field to
access to the Call Log of that selected account.
 Menu
Settings  Programmable Keys  Virtual Multi-Purpose Keys (VPK) (For GXP2170 only)
VPK
Assigns a function to the corresponding line key. The key mode options
are:
 Line
Regular line key to open up a line and switch line. The Value field
can be left blank.
 Shared Line
Share line for Shared Line Appearance feature. Select the Account
registered as Shared line for the line key. The Value field can be left
blank.
 Speed Dial
Select the Account to dial from. And enter the Speed Dial number in
the Value field to be dialed, or enter the IP address to set the Direct
IP call as Speed Dial.
 Busy Lamp Field (BLF)
Select the Account to monitor the BLF status. Enter the extension
number in the Value field to be monitored.
 Presence Watcher
This option has to be supported by a presence server and it is tied to
the "Do Not Disturb" status of the phone's extension.
 Eventlist BLF
This option is similar to the BLF option but in this case the PBX
collects the information from the phones and sends it out in one
single notify message. PBX server has to support this feature.
 Speed Dial via active account
