 Multicast Paging
This option is for multicast sending. Enter Line key description in
Description filed and multicast sending address in Value field.
 Record
This option is for Recording calls. Enter Line key description in
Description filed and the recorded extension number in Value field.
Please make sure whether your VOIP provider supports this feature
before using it.
 Call Log
Select Account and enter account number in the Value field to
access to the Call Log of that selected account.
Settings  Programmable Keys  Programmable Keys (For GXP2170 only)
Softkeys
Assigns a function to the corresponding softkeys. GXP2140/GXP2160
supports 3 configurable softkeys; GXP2130 supports 3 configurable
softkeys. (The first and last softkeys are reserved for Exit/More
functionality.)
The key mode options are:
 Speed Dial
Select the Account to dial from. And enter the Speed Dial number in
the Value field to be dialed.
 Speed Dial via active account
Similar to Speed Dial but it will dial based on the current active
account. For example, if the phone is offhook and account 2 is active,
it will call the configured Speed Dial number using account 2.
 Voice Mail
Select Account and enter the Voice Mail access number in the Value
field.
 Call Return
The last answered calls can be dialed out by using Call Return. The
Value field should be left blank. Also, this option is not binding to the
account and the call will be returned based on the account with the
last answered call.
 Intercom
Select Account, and enter the extension number in the Value field to
do the intercom.
 LDAP Search
This option is to narrow the LDAP search scope. Enter the LDAP
search base in the Description field. It could be the same or different
from the Base in LDAP configuration under Advanced Settings. The
