User's Manual

GXP2130/GXP2140/GXP2160/GXP2170
ADMINISTRATION GUIDE
Page 19 of 87
Network Interfaces
Dual switched auto-sensing 10/100/1000 Mbps Gigabit Ethernet ports with
integrated PoE
Graphic Display
4.3 inch (480x272) TFT color LCD
Bluetooth
Yes, Bluetooth V2.1
Feature Keys
12 line keys with up to 6 SIP accounts or 48 provisionable BLF/fast-dial keys, 5
programmable context sensitive softkeys, 5 navigation/menu keys, 11 dedicated
function keys for: MESSAGE (with LED indicator), PHONEBOOK, TRANSFER,
CONFERENCE, HOLD, HEADSET, MUTE, SEND/REDIAL, SPEAKERPHONE,
VOL+, VOL
Voice Codec
Support for G.729A/B, G.711µ/a-law, G.726, G.722 (wide-band), in-band and
out-of-band DTMF (in audio, RFC2833, SIP INFO)
Auxiliary Ports
RJ9 headset jack (allowing EHS with Plantronics headsets), USB, extension
module port
Telephony Features
Hold, transfer, forward, 5-way conference, call park, call pickup,
shared-call-appearance (SCA)/bridged-line-appearance (BLA), downloadable
phonebook (XML, LDAP, up to 2000 items), call waiting, call log (up to 500
records), customization of screen, off-hook auto dial, auto answer, click-to-dial,
flexible dial plan, hot desking, personalized music ringtones and music on hold,
server redundancy and fail-over
Sample Applications
Weather, currency, news
GMI available for advanced custom application development
HD audio
Yes, both on handset and speakerphone
Extension Module
Yes, can power up up to 4 GXP2200EXT modules which features a 128x384
graphic LCD, 20 quick-dial/BLF keys which dual-color LED, 2 navigation keys,
and less than 1.2W power consumption per unit.
Base Stand / Wall
Mountable
Yes, allow 2 angle positions
QoS
Layer 2 (808.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS
Security
User and administrator level passwords, MD5 and MD5-sess based
authentication, AES based secure configuration file, SRTP, TLS, 802.1x media
access control
Multi-language
English, Arabic, Chinese, Croatian, Czech, Dutch, German, French, Hebrew,
Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Slovenia,
Spanish, Turkish
Upgrade/Provisioning
Firmware upgrade via TFTP/HTTP/HTTPS, mass provisioning using TR-069 or
encrypted XML configuration file
Power & Green
Energy Efficiency
Universal power adapter included:
Input:100-240V; Output: +12V, 1.0A ;
Integrated Power-over-Ethernet (802.3af)
Max power consumption: 6W (without GXP2200EXT), 10W(with 4 cascaded
