Specification

© 2019 BendPak Inc. All rights reserved.
1645 Lemonwood Drive, Santa Paula, CA 93060 USA • Toll-free 1-800-253-2363 • Fax [phone]
2-Post Lift / 7,000-lb. Capacity / 118.5” Overall Height
SKU# 5175996
GP-7LC
7,000 lbs. (3,175 kg)
54" (1,372 mm)
58" (1,473 mm)
66" (1,676 mm)
4.5” (114 mm)
106.5" (2,705 mm)
125" (3,175 mm)
89.5" (2,273 mm)
96" (2,438 mm)
220 VAC / 60Hz / 1 Ph
GP-7LCS
Lifting Capacity
Rise
Rise + Pad Only
Rise + Pad + 63 mm Adapter
Min. Height + Pad
Height Overall
Width Overall
Drive-Thru Clearance
Floor to Overhead Switch
Motor
SPECIFICATIONS
7,000 lbs. (3,175 kg)
64" (1,626 mm)
68" (1,727 mm)
76" (1,930 mm)
4.5” (114 mm)
118.5" (3,010 mm)
125" (3,175 mm)
89.5" (2,273 mm)
108" (2,743 mm)
220 VAC / 60Hz / 1 Ph
GP-7LC
7,000 lbs. (3,175 kg)
74" (1,880 mm)
78" (1,981 mm)
86.5" (2,197 mm)
4.5” (114 mm)
150" (3,810 mm)
125" (3,175 mm)
89.5" (2,273 mm)
140" (3,556 mm)
220 VAC / 60Hz / 1 Ph
GP-7
FEATURES
Single hidden overhead cylinder
Low-Pro
™
arms for sports cars
Taller lift carriages
Automatic safety locks
Redundant safety cables
Multiple lock positions
5-Year Warranty
FOR THE HOME WRENCHER
The GP-7LC is an incredibly powerful, 7,000-lb.
capacity two-post lift that reaches a max lifting
height of 68”. Never before has a garage with ceilings
as low as 10’ been able to t a lift of this caliber. Only
the GrandPrix offers the superior safety standards
of a full-rise lift in a slim, low-ceiling build. Home
wrenchers have long lamented the lack of a lifting
option for their garages, so they wind up settling for
less premium options or low-rise options, or else
they make sacrices in the capabilities and safety
features of their lift. GrandPrix’s GP-7LC truly upends
everything you thought you knew about automotive
repair. This machine ts in most home garages and
comes along with the best warranty in the industry. If
you’ve been holding off because of space, this might
just be the lift for you’ve been looking for.
