Specification

© 2019 BendPak Inc. All rights reserved.
1645 Lemonwood Drive, Santa Paula, CA 93060 USA • Toll-free 1-800-253-2363 • Fax [phone]
2-Post Lift / 7,000-lb. Capacity / 106.5” Overall Height
SKU# 5175995
GP-7LCS
7,000 lbs. (3,175 kg)
54" (1,372 mm)
58" (1,473 mm)
66" (1,676 mm)
4.5” (114 mm)
106.5" (2,705 mm)
125" (3,175 mm)
89.5" (2,273 mm)
96" (2,438 mm)
220 VAC / 60Hz / 1 Ph
GP-7LCS
Lifting Capacity
Rise
Rise + Pad Only
Rise + Pad + 63 mm Adapter
Min. Height + Pad
Height Overall
Width Overall
Drive-Thru Clearance
Floor to Overhead Switch
Motor
SPECIFICATIONS
7,000 lbs. (3,175 kg)
64" (1,626 mm)
68" (1,727 mm)
76" (1,930 mm)
4.5” (114 mm)
118.5" (3,010 mm)
125" (3,175 mm)
89.5" (2,273 mm)
108" (2,743 mm)
220 VAC / 60Hz / 1 Ph
GP-7LC
7,000 lbs. (3,175 kg)
74" (1,880 mm)
78" (1,981 mm)
86.5" (2,197 mm)
4.5” (114 mm)
150" (3,810 mm)
125" (3,175 mm)
89.5" (2,273 mm)
140" (3,556 mm)
220 VAC / 60Hz / 1 Ph
GP-7
FEATURES
Single hidden overhead cylinder
Low-Pro
™
arms for sports cars
Taller lift carriages
Automatic safety locks
Redundant safety cables
Multiple lock positions
5-Year Warranty
ULTIMATE LOW-CEILING LIFT
The game-changing upside of the GP-7LCS is that it
stands at just 8’ 10”. Even if it doesn’t offer as much
rise as high as other two-post lifts, its impressive 58”
lifting height is still more than what you get with low-
prole, mid-rise scissor lifts. So, if you’re between a
scissor lift and a GrandPrix, the GP-7LCS ultimately
offers more lifting height.
It’s hard to overstate how different the GP-7LCS
is from any other garage lift. Two-post lifts have
long been standard equipment for professional
service bays, but many DIY’ers have been waiting
for the day a model would come along that ts in
an average-size garage. GrandPrix comes with the
same great industry-best warranty as other BendPak
two-posts lifts.
