Concrete Foundation Recommendations for GSI CFL Grain Bins Instruction Manual PNEG-1867 Date: 05-31-12 PNEG-1867
PNEG-1867 Concrete Foundation Recommendations for GSI CFL Grain Bins
Table of Contents Contents Chapter 1 CFL Series Outside Universal Stiffened Anchor Bolt Charts ........................................................... 6 CFL Series Outside Universal Stiffened Anchor Bolt Charts 4" Corrugation Commercial Farm Tanks ............................................................................................... 6 Chapter 2 Inverted “T” Foundation 4" Outside Stiffened (CFL Series) Commercial Farm Tanks ................ 10 3000 PSF Soil Bearing Capacity ....................
NOTES 4 PNEG-1867 Concrete Foundation Recommendations for GSI CFL Grain Bins
Section 1 ® CFL (4" Corrugation) Outside Stiffened Anchor Bolt Chord Charts 2 Post Commercial Farm Tanks PNEG-1867 Concrete Foundation Recommendations for GSI CFL Grain Bins 5
1. CFL Series Outside Universal Stiffened Anchor Bolt Charts CFL Series Outside Universal Stiffened Anchor Bolt Charts 4" Corrugation Commercial Farm Tanks Prior to setting any anchor bolts, you must be sure to have the correct anchor bolt placement chart. This is very critical for stiffener alignment during erection.
1.
NOTES 8 PNEG-1867 Concrete Foundation Recommendations for GSI CFL Grain Bins
Section 2 ® Inverted “T” Foundation Recommendations for 4" Corrugation Outside Stiffened Commercial Farm Tanks (CFL Series) PNEG-1867 Concrete Foundation Recommendations for GSI CFL Grain Bins 9
2. Inverted “T” Foundation 4" Outside Stiffened (CFL Series) Commercial Farm Tanks 3000 PSF Soil Bearing Capacity Inverted “T” Foundation Notes: 1. The foundation design is based on a minimum allowable soil bearing capacity of 3000 PSF. Bearing capacity of the soils should be determined by geotechnical investigation and be of uniform bearing capacity. 2. The foundation site must be free of vegetation and debris and well drained. 3.
2.
2. Inverted “T” Foundation 4" Outside Stiffened (CFL Series) Commercial Farm Tanks 3500 PSF Soil Bearing Capacity Inverted “T” Foundation Notes: 1. The foundation design is based on a minimum allowable soil bearing capacity of 3500 PSF. Bearing capacity of the soils should be determined by geotechnical investigation and be of uniform bearing capacity. 2. The foundation site must be free of vegetation and debris and well drained. 3.
2.
2. Inverted “T” Foundation 4" Outside Stiffened (CFL Series) Commercial Farm Tanks 4000 PSF Soil Bearing Capacity Inverted “T” Foundation Notes: 1. The foundation design is based on a minimum allowable soil bearing capacity of 4000 PSF. Bearing capacity of the soils should be determined by geotechnical investigation and be of uniform bearing capacity. 2. The foundation site must be free of vegetation and debris and well drained. 3.
2.
NOTES 16 PNEG-1867 Concrete Foundation Recommendations for GSI CFL Grain Bins
Section 3 ® T-Cap Foundation Recommendations for CFL 4" Corrugation Outside Stiffened Commercial Farm Tanks PNEG-1867 Concrete Foundation Recommendations for GSI CFL Grain Bins 17
3. T-Cap Foundation Outside Stiffened Commercial Farm Tanks T-Cap Foundation Notes: 1. The foundation design is based on a minimum allowable soil bearing capacity as specified on each chart. Bearing capacity of the soils should be determined by geotechnical investigation and be of uniform bearing capacity. 2. The foundation site must be free of vegetation and debris and well drained. 3. The foundation must be founded below the frost line or constructed on non-expansive frost free fill. 4.
3. T-Cap Foundation Outside Stiffened Commercial Farm Tanks Diameter of Bin: 54' Soil Bearing Capacity: 4000 PSF Rings Rebar Cu. Yds. Concrete 20 21 A 1'-5" 1'-7" B 8'-0" 9'-0" C 27'-11" 27'-11" D 31'-3" 31'-9" E 1'-4" 1'-4" F 1'-1" 1'-3" G 0'-8" 0'-8" M 5 #5's 5 #5's N 10 #5's 10 #6's P #5 @ 8" c/c #6 @ 9" c/c Q #5 @ 16" c/c #6 @ 18" c/c R #4 @ 12" c/c #5 @ 12" c/c #4 (ft.) 2900 0 #5 (ft.) 12600 11200 #6 (ft.
NOTES 20 PNEG-1867 Concrete Foundation Recommendations for GSI CFL Grain Bins
4. Warranty GSI Group, LLC Limited Warranty The GSI Group, LLC (“GSI”) warrants products which it manufactures to be free of defects in materials and workmanship under normal usage and conditions for a period of 12 months after sale to the original end-user or if a foreign sale, 14 months from arrival at port of discharge, whichever is earlier.
This equipment shall be installed in accordance with the current installation codes and applicable regulations, which should be carefully followed in all cases. Authorities having jurisdiction should be consulted before installations are made. GSI Group 1004 E. Illinois St. Assumption, IL 62510-0020 Phone: 1-217-226-4421 Fax: 1-217-226-4420 www.gsiag.
