44 PNEG-1833 75' Dura-Lok Plank and Support Manual
75' Dura-Lok Bundle Layout (Continued)
NOTES:
1. Looking from end of the bundle where all plank edges are butted flush.
2. One AB2 bundle required for complete order. Two (2) AB1 bundles, one C1 bundles and
one C2 bundles also needed.
3. Plank banding and sub-banding denoted by grid lines in charts.
C1
Plank Layout by Marking
Plank Layout by Length
4B 3B 2B 1 104 153-1/2 58-1/2 105
8C 4A 3A 2A
240 176 81-1/2 130-1/2
15C 13C 11C 9C 240 240 240 240
16C 14C 12C 10C 240 240 240 240
23C 21C 19C 17C 240 240 240 240
24C 22C 20C 18C
240 240 240 240
31C 29C 27C 25C 240 240 240 240
32C 30C 28C 26C 240 240 240 240
39C 37C 35C 33C 240 240 240 240
40C 38C 36C 34C
240 240 240 240
47C 45C 43C 41C 240 240 240 240
48C 46C 44C 42C 240 240 240 240
55C 53C 51C 49C 240 240 240 240
56C 54C 52C 50C
240 240 240 240
63C 61C 59C 57C 240 240 240 240
64C 62C 60C 58C 240 240 240 240
C2
Plank Layout by Marking
Plank Layout by Length
4B 3B 2B 104 153-1/2 58-1/2
4A 3A 2A 1 176 81-1/2 130-1/2 105
14C 12C 10C 8C 240 240 240 240
15C 13C 11C 9C 240 240 240 240
22C 20C 18C 16C 240 240 240 240
23C 21C 19C 17C 240 240 240 240
30C 28C 26C 24C 240 240 240 240
31C 29C 27C 25C 240 240 240 240
38C 36C 34C 32C 240 240 240 240
39C 37C 35C 33C 240 240 240 240
46C 44C 42C 40C 240 240 240 240
47C 45C 43C 41C 240 240 240 240
54C 52C 50C 48C 240 240 240 240
55C 53C 51C 49C 240 240 240 240
62C 60C 58C 56C 240 240 240 240
63C 61C 59C 57C 240 240 240 240
