6. Layouts
PNEG-1833 75' Dura-Lok Plank and Support Manual 43
75' Dura-Lok Bundle Layout
NOTES:
1. Looking from end of the bundle where all plank edges are butted flush.
2. One AB2 bundle required for complete order. Two (2) AB1 bundles, one C1 bundle and
one C2 bundle also needed.
3. Plank banding and sub-banding denoted by grid lines in charts.
AB1
Plank Layout by Marking
Plank Layout by Length
9A 7A 5A 93 66-1/2 34
10B 8B 6B 105 80 51
9B 7B 5B 105 78-1/2 46
10A 8A 6A 117 92 63
17A 15A 13A 11A 171 154 136 116
18B 16B 14B
12B 178 163 145 126
17B 15B 13B 11B 183 166 148 128
18A 16A 14A 12A 190 175 157 138
25A 23A 21A 19A 224 212-1/2 200 185-1/2
26B 24B 22B 20B 229 218-1/2 206 192-1/2
25B 23B 21B 19B 236 224-1/2 212 197-1/2
26A 24A 22A 20A 241 230-1/2 218 204-1/2
33A 31A 29A 27A 262 253 244 234-1/2
34B 32B 30B 28B 265-1/2 257 249 238
33B 31B 29B 27B 274 265 256 246-1/2
34A 32A 30A 28A 277-1/2 269 261 250
41A 39A 37A 35A 288-1/2 282-1/2 276-1/2 269
42B 40B 38B 36B 291-1/2 285-1/2 279-1/2 273
41B 39B 37B 35B 300-1/2 294-1/2 288-1/2 281
42A 40A 38A 36A 303-1/2 297-1/2 291-1/2 285
49A 47A 45A 43A 305-1/2 311-1/2 298-1/2 294
50B 48B 46B 44B 307 303-1/2 299-1/2 296
49B 47B 45B 43B 317-1/2 313-1/2 310-1/2 306
50A 48A 46A 44A 319 315-1/2 311-1/2 308
AB2
Plank Layout by Marking
Plank Layout by Length
51A 51B 51B 51A 308-1/2 331 331 308-1/2
52B 52A 52A 52B 310 322 322 310
53A 55A 55A 53A 311-1/2 314 314 311-1/2
54B 56B 56B 54B 312-1/2 315 315 312-1/2
53B 55B 55B 53B 323-1/2 326 326 323-1/2
54A 56A 56A 54A 324-1/2 327 327 324-1/2
57A 59A 59A 57A 315-1/2 317 317 315-1/2
58B 60B 60B 58B 316-1/2 317-1/2 317-1/2 316-1/2
57B 59B 59B 57B 327-1/2 329 329 327-1/2
58A 60A 60A 58A 328-1/2 329-1/2 329-1/2 328-1/2
61A 63A 63A 61A 330 318-1/2 318-1/2 330
62B 64B 64B 62B 318-1/2 318-1/2 318-1/2 318-1/2
61B 63B 63B 61B 330 330-1/2 330-1/2 330
62A 64A 64A 62A 330-1/2 330-1/2 330-1/2 330-1/2
