Instruction Manual

6. Layouts
44 PNEG-1832 72' Dura-Lok Plank and Support Manual
72' Plank Layout for Manual
Plank #
Length
Plank A
In Inch In Metric Plank #
Length
Plank B
In Inch In Metric
1 8'-0" 96 243.84
2A 4' - 6-1/2" 54-1/2 138.43 2B 10' - 6-1/2" 126-1/2 321.31
3A 12' - 10-1/2" 154-1/2 392.43 3B 6' - 10-1/2" 82-1/2 209.55
4A 8'-8" 104 264.16
4B 14' - 8-1/2" 176-1/2 448.31
5A 16'-2" 194 492.76 5B 10'-2" 122 309.88
6A 11' - 6-1/2" 138-1/2 351.79
6B 17' - 6-1/2" 210-1/2 534.67
7A 18' - 9-1/2" 225-1/2 572.77 7B 12' - 9-1/2" 153-1/2 389.89
8A 13'-11" 167 424.18
8B 19'-11" 239 607.06
9A 20' - 11-1/2" 251-1/2 638.81 9B 14' - 11-1/2" 179-1/2 455.93
10A 15'-11" 191 485.14
10B 21'-11" 263 668.02
11A 22'-10" 274 695.96 11B 16'-10" 202 513.08
12A 17'-8" 212 538.48
12B 23'-8" 284 721.36
13A 24' - 4-1/2" 292-1/2 742.95 13B 18' - 4-1/2" 220-1/2 560.07
14A 19' - 1-1/2" 229-1/2 582.93
14B 25' - 1-1/2" 301-1/2 765.81
15A 25'-10" 310 787.4 15B 19'-10" 238 604.52
16A 20' - 6-1/2" 246-1/2 626.11
16B 26' - 6-1/2" 318-1/2 808.99
17A 27'-2" 326 828.04 17B 21'-2" 254 645.16
18A 21' - 9-1/2" 261-1/2 664.21
18B 27' - 9-1/2" 333-1/2 847.09
19A 28' - 4-1/2" 340-1/2 864.87 19B 22' - 4-1/2" 270-1/2 687.07
20A 22'-11" 275 698.5
20B 28'-11" 347 881.38
21A 29' - 5-1/2" 353-1/2 897.89 21B 23' - 5-1/2" 281-1/2 715.01
22A 23' - 11-1/2" 287-1/2 730.25
22B 29' - 11-1/2" 359-1/2 913.13
23A 30' - 5-1/2" 365-1/2 928.37 23B 24' - 5-1/2" 293-1/2 745.49
24A 24'-11" 299 759.46
24B 30'-11" 371 942.34
25A 31' - 4-1/2" 376-1/2 956.31 25B 25' - 4-1/2" 304-1/2 773.43
26A 25'-10" 310 787.4
26B 31'-10" 382 970.28
27A 32'-3" 387 982.98 27B 26'-3" 315 800.1
28A 26' - 7-1/2" 319-1/2 811.53
28B 32' - 7-1/2" 391-1/2 994.41
29A 33'-0" 396 1005.84 29B 27'-0" 324 822.96
30A 27' - 4-1/2" 328-1/2 834.39
30B 33' - 4-1/2" 400-1/2 1017.27
31A 33'-9" 405 1028.7 31B 27'-9" 333 845.82
32A 28'-1/2" 336-1/2 854.71
32B 34'-1/2" 408-1/2 1037.59
33A 34' - 4-1/2" 412-1/2 1047.75 33B 28' - 4-1/2" 340-1/2 864.87
34A 28'-8" 344 873.76
34B 34'-8" 416 1056.64
35A 34' - 11-1/2" 419-1/2 1065.53 35B 28' - 11-1/2" 347-1/2 882.65
36A 29'-3" 351 891.54
36B 35'-3" 423 1074.42
37A 35'-6" 426 1082.04 37B 29'-6" 354 899.16
38A 29'-9" 357 906.78
38B 35'-9" 429 1089.66
39A 36'-0" 432 1097.28 39B 30'-0" 360 914.4
40A 30'-3" 363 922.02
40B 36'-3" 435 1104.9
41A 36' - 5-1/2" 437-1/2 1111.25 41B 30' - 5-1/2" 365-1/2 928.37
42A 30'-8" 368 934.72
42B 36'-8" 440 1117.6
43A 36' - 10-1/2" 442-1/2 1123.95 43B 30' - 10-1/2" 370-1/2 941.07
44A 31'-1/2" 372-1/2 946.15
44B 37'-1/2" 444-1/2 1129.03
45A 37'-3" 447 1135.38 45B 31'-3" 375 952.5
46A 31' - 4-1/2" 376-1/2 956.31
46B 37' - 4-1/2" 448-1/2 1139.19
47A 37' - 6-1/2" 450-1/2 1144.27 47B 31' - 6-1/2" 378-1/2 961.39
48A 31'-8" 380 965.2
48B 37'-8" 452 1148.08
49A 37'-10" 454 1153.16 49B 31'-10" 382 970.28
50A 31' - 11-1/2" 383-1/2 974.09
50B 37' - 11-1/2" 455-1/2 1156.97
51A 38'-1/2" 456-1/2 1159.51 51B 32'-1/2" 384-1/2 976.63
52A 32'-2" 386 980.44
52B 38'-2" 458 1163.32
53A 38'-3" 459 1165.86 53B 32'-3" 387 982.98
54A 32'-4" 388 985.52
54B 38'-4" 460 1168.4
55A 38'-5" 461 1170.94 55B 32'-5" 389 988.06
56A 32' - 5-1/2" 389-1/2 989.33
56B 38' - 5-1/2" 461-1/2 1172.21
57A 38'-6" 462 1173.48 57B 32'-6" 390 990.6
58A 32' - 6-1/2" 390-1/2 991.87
58B 38' - 6-1/2" 462-1/2 1174.75
59A 38'-7" 463 1176.02 59B 32'-7" 391 993.14
60A 32'-7" 391 993.14
60B 38'-7" 463 1176.02
61A 38'-8" 464 1178.56 61B 32'-8" 392 995.68
