PNEG-1832 72' Dura-Lok Plank and Support Manual 29
6. Layouts
72'-15" Rail Spacing Layout
Figure 6D 72' Diameter 15" Rail Spacing
NOTE: This depicts monorail spacings only. Leg spacing is dependant
on eave height. See Page 18 for leg and rail spacing chart.
Tie bar (See Page 15 for
installation detail.)
