54' Plank Layout for Manual
Plank #
Length
Plank A
In Inch In Metric Plank #
Length
Plank B
In Inch In Metric
1A 2'-4" 28 71.12
2A 8' - 7-1/2" 103-1/2 262.89 2B 2' - 7-1/2" 31-1/2 80.01
3A 4' - 10-1/2" 58-1/2 148.59 3B 10' - 10-1/2" 130-1/2 331.47
4A 12'-6" 150 381
4B 6'-6" 78 198.12
5A 7' - 10-1/2" 94-1/2 240.03 5B 13' - 10-1/2" 166-1/2 422.91
6A 15'-1" 181 459.74
6B 9'-1" 109 276.86
7A 10'-2" 122 309.88 7B 16'-2" 194 492.76
8A 17'-2" 206 523.24
8B 11'-2" 134 340.36
9A 12'-0" 144 365.76 9B 18'-0" 216 548.64
10A 18'-9" 225 571.5
10B 12'-9" 153 388.62
11A 13'-6" 162 411.48 11B 19'-6" 234 594.36
12A 20'-3" 243 617.22
12B 14'-3" 171 434.34
13A 14'-11" 179 454.66 13B 20'-11" 251 637.54
14A 21'-6" 258 655.32
14B 15'-6" 186 472.44
15A 18'-1" 217 551.18 15B 22'-1" 265 673.1
16A 22'-8" 272 690.88 16B 16'-8" 200 508
17A 17'-2" 206 523.24 17B 23'-2" 278 706.12
18A 23'-8" 284 721.36
18B 17'-8" 212 538.48
19A 18'-1" 217 551.18 19B 24'-1" 289 734.06
20A 24'-6" 294 746.76
20B 18'-6" 222 563.88
21A 18'-11" 227 576.58 21B 24'-11" 299 759.46
22A 25'-4" 304 772.16
22B 19'-4" 232 589.28
23A 19'-8" 236 599.44 23B 25'-8" 308 782.32
24A 26'-1" 313 795.02
24B 20'-1" 241 612.14
25A 20'-5" 245 622.3 25B 26'-5" 317 805.18
26A 26'-8" 320 812.8
26B 20'-8" 248 629.92
27A 21'-0" 252 640.08 27B 26'-0" 312 792.48
28A 27'-3" 327 830.58
28B 21'-3" 255 647.7
29A 21'-6" 258 655.32 29B 27'-6" 330 838.2
30A 27'-9" 333 845.82
30B 21'-9" 261 662.94
31A 22'-0" 264 670.56 31B 28'-0" 336 853.44
32A 28'-2" 338 858.52
32B 22'-2" 266 675.64
33A 22'-5" 269 683.26 33B 28'-5" 341 866.14
34A 28'-7" 343 871.22
34B 22'-7" 271 688.34
35A 22'-9" 273 693.42 35B 28'-9" 345 876.3
36A 28'-10" 346 878.84
36B 22'-10" 274 695.96
37A 23'-0" 276 701.04 37B 29'-0" 348 883.92
38A 29'-1" 349 886.46
38B 23'-1" 277 703.58
39A 23'-3" 279 708.66 39B 29'-3" 351 891.54
40A 29'-4" 352 894.08
40B 23'-4" 280 711.2
41A 23'-5" 281 713.74 41B 29'-5" 353 896.62
42A 29'-6" 354 899.16
42B 23'-6" 282 716.28
43A 23'-6" 282 716.28 43B 29'-6" 354 899.16
44A 29'-7" 355 901.7
44B 23'-7" 283 718.82
45A 23'-7" 283 718.82 45B 29'-7" 355 901.7
46A 29'-7" 355 901.7
46B 23'-7" 283 718.82
