Decals (cont.)
DO NOT INSERT HAND IN
OPENING WHILE ENGINE
IS RUNNING
9103-3011
Located on Engine Cover
Part No. 9103-3011
DO NOT USE OXYGEN
USE “OIL PUMPED OR DRY NITROGEN.”
CONSULT DEALER BEFORE CHARGING ACCUMULATOR
9104-3206
Located on Accumulator
Part No.9104-3206
PINCH POINT AREA
TO PREVENT INJURY, KEEP
CLEAR ANYTIME MACHINE
IS RUNNING.
9104-3209
Located on Rear of Frame
Part No.9104-3209
TO PREVENT
INJURY, KEEP
OUT OF BOOM
HOLES.
Located on each side of boom
Part No. 7702-3009
7702-3009
8
PRESSURIZED-
COOLING SYSTEM
REMOVE CAP
SLOWLY
9104-3210
NO RIDERS
9104-3211
Located at Cab Entrance &
on Engine Cover
Part No. 9104-3211
Located on Engine Cover
Part No. 9104-3210
DO NOT USE THIS MACHINE
FOR LIFTING PERSONEL.
Located on Mudguard
Part No. 9104-3215
9104-3215
INSURE FORKS ARE LEVEL AND
LOAD IS SECURE BEFORE ROTATING
LOAD WHEN EQUIPPED WITH SWING
FORKS. BOOM SHOULD BE PROPERLY
SHIMMED TO MINIMIZE TWIST.
LOSS OF LOAD WILL RESULT FROM
MISSUE OF SWING FORKS.
9104-3173
Located on left cab wall
Part No. 9104-3173
