Typical Installation
4 3A1149D
Typical Installation
Key:
A Discrete Gateway Module (DGM)
B Breakout Board
CCAN Cables
D 78 Pin D-Sub Cables (Male to Female)
E Ground screw
F Connects to HFR
G Ferrite Suppressor
