User's Manual

Troubleshooting
32 3A1149D
00101101 A (Red) Oil Temp. Shutdown 45 A T 4 H 2
00101110 A (Red) Oil Temp. Cutback 46 D T 3 H 2
00101111 A (Red) Low Oil Level 47 A M B H 2
00110000 A (Red) Motor Over Current 48 A A 4 H 2
00110001 A (Red) Motor Over Current 49 A A 4 N 2
00110010 A (Red) Motor Over Current 50 A A 4 M 2
00110011 A (Red) Motor Over Current 51 A A 9 C 2
00110100
A (Red) Motor Control High
Te mp.
52 A T 4 C 2
00110101
A (Red) Motor Control Over-
voltage
53 A V 4 H 0
00110110
A (Red) Motor Control Under-
voltage
54 A V 1 H 2
00110111 A (Red) Motor Encoder Fault 55 A W B H 2
00111000 A (Red) Motor Controller Fault 56 A W M H 2
00111001
A (Red) Low Motor Perfor-
mance
57 A M B N 2
00111010 A (Red) High Motor Speed 58 A W K H 2
00111011 A (Red) Pump Failed to Move 59 A N 4 B 0
00111100 Invalid Requested Ratio 60 A R 9 C 0
00111101 Invalid Learn Mode Data 61 A D 5 B 2
00111110 Invalid Auto Cal B (Blue)? 62 0 0000
00111111 A (Red) Position Sensor Fault 63 A D 6 B 2
01000000 A (Red) Setpoint Not Reached 64 D D 1 A 2
01000001 A (Red) Setpoint Not Reached 65 D D 2 A 2
01000010 A (Red) Setpoint Exceeded 66 D D 4 A 2
01000011 A (Red) Setpoint Exceeded 67 D D 3 A 2
01000100 A (Red) Pressure Shutdown 68 A P 4 A 1
01000101 A (Red) Pump Not Parked 69 D D F B 2
01000110 A (Red) Pump Failed to Stall 70 A F 7 D 2
01000111 Another Cal Error? 71 0 0000
01001000
A (Red) Thermal Pressure
Rise?
72 DP401
01001001 A (Red) Blanket Temp. Cutoff 73 A T 9 A 6
01001010 B (Blue) Blanket Temp. Cutoff 74 A T 9 B 5
01001011 A (Red) Inline Temp. Cutoff 75 A T 9 A 3
01001100 B (Blue) Inline Temp. Cutoff 76 A T 9 B 1
01001101 No A (Red) Blanket Current 77 A A 8 A 6
01001110 No B (Blue) Blanket Current 78 A A 8 B 5
01001111 No A (Red) Inline Current 79 A A 8 A 3
01010000 No B (Blue) Inline Current 80 A A 8 B 1
01010001 No A (Red) Hose Current 81 A A 8 A 2
01010010 No B (Blue) Hose Current 82 A A 8 B 4
01010011 No A (Red) Chiller Current 83 A A 8 B 7
01010100 No B (Blue) Chiller Current 84 A A 8 B 8
01010101 A (Red) Blanket Overcurrent 85 A A 4 A 6
01010110 B (Blue) Blanket Overcurrent 86 A A 4 B 5
01010111 A (Red) Inline Overcurrent 87 A A 4 A 3
01011000 B (Blue) Inline Overcurrent 88 A A 4 B 1
01011001 A (Red) Hose Overcurrent 89 A A 4 A 2
01011010 B (Blue) Hose Overcurrent 90 A A 4 B 4
01011011 A (Red) Chiller Overcurrent 91 A A 4 A 7
01011100 B (Blue) Chiller Overcurrent 92 A A 4 B 8
01011101 A (Red) Blanket Control Fault 93 A A 7 A 6
01011110 B (Blue) Blanket Control Fault 94 A A 7 B 5
01011111 A (Red) Inline Control Fault 95 A A 7 A 3
01100000 B (Blue) Inline Control Fault 96 A A 7 B 1
01100001 A (Red) Hose Control Fault 97 A A 7 A 2
01100010 B (Blue) Hose Control Fault 98 A A 7 B 4
Fault Code
Bit Pattern
(Bit 7 --> Bit 0)
Error String
Error
Number
Error Code
Shown on the
ADM
01100011 A (Red) Chiller Control Fault 99 A A 7 A 7
01100100 B (Blue) Chiller Control Fault 100 A A 7 B 8
01100101 A (Red) Blanket Overvoltage 101 A V 4 A 6
01100110 B (Blue) Blanket Overvoltage 102 A V 4 B 5
01100111 A (Red) Inline Overvoltage 103 A V 4 A 3
01101000 B (Blue) Inline Overvoltage 104 A V 4 B 1
01101001 A (Red) Hose Overvoltage 105 A V 4 A 2
01101010 B (Blue) Hose Overvoltage 106 A V 4 B 4
01101011 A (Red) Chiller Overvoltage 107 A V 4 A 7
01101100 B (Blue) Chiller Overvoltage 108 A V 4 B 8
01101101 A (Red) Blanket Undervoltage 109 A V 4 A 6
01101110 B (Blue) Blanket Undervoltage 110 A V 4 B 5
01101111 A (Red) Inline Undervoltage 111 A V 4 A 3
01110000 B (Blue) Inline Undervoltage 112 A V 4 B 1
01110001 A (Red) Hose Undervoltage 113 A V 4 A 2
01110010 B (Blue) Hose Undervoltage 114 A V 4 B 4
01110011 A (Red) Chiller Undervoltage 115 A V 4 A 7
01110100 B (Blue) Chiller Undervoltage 116 A V 4 B 8
01110101
A (Red) Blanket Ctrl Shut-
down
117 A T 9 C 6
01110110
B (Blue) Blanket Ctrl Shut-
down
118 A T 9 C 5
01110111 A (Red) Inline Ctrl Shutdown 119 A T 9 C 3
01111000 B (Blue) Inline Ctrl Shutdown 120 A T 9 C 1
01111001 A (Red) Hose Ctrl Shutdown 121 A T 9 C 2
01111010 B (Blue) Hose Ctrl Shutdown 122 A T 9 C 4
01111011 A (Red) Chiller Ctrl Shutdown 123 A T 9 C 7
01111100 B (Blue) Chiller Ctrl Shutdown 124 A T 9 C 8
01111101 A (Red) Tank Con. Cutback 125 V W M C 6
01111110 B (Blue) Tank Con. Cutback 126 V W M C 5
01111111 A (Red) Inline Con. Cutback 127 V W M C 3
10000000 B (Blue) Inline Con. Cutback 128 V W M C 1
10000001 A (Red) Hose Con. Cutback 129 V W M C 2
10000010 B (Blue) Hose Con. Cutback 130 V W M C 4
10000011 A (Red) Chiller Con. Cutback 131 V W M C 7
10000100 B (Blue) Chiller Con. Cutback 132 V W M C 8
10000101 A (Red) Tank High Fluid Temp. 133 A T 4 A 6
10000110
B (Blue) Tank High Fluid
Tem p.
134 A T 4 B 5
10000111
A (Red) Inline High Fluid
Tem p.
135 A T 4 A 3
10001000
B (Blue) Inline High Fluid
Tem p.
136 A T 4 B 1
10001001
A (Red) Hose High Fluid
Tem p.
137 A T 4 A 2
10001010
B (Blue) Hose High Fluid
Tem p.
138 A T 4 B 4
10001011
A (Red) Chiller High Fluid
Tem p.
139 D T 4 A 7
10001100
B (Blue) Chiller High Fluid
Tem p.
140 D T 4 B 8
10001101 A (Red) Blanket High Temp. 141 A W M A 6
10001110 B (Blue) Blanket High Temp. 142 A W M B 5
10001111 A (Red) Tank Low Fluid Temp. 143 D T 1 A 6
10010000 B (Blue) Tank Low Fluid Temp. 144 D T 1 B 5
10010001
A (Red) Inline Low Fluid
Tem p.
145 D T 1 A 3
10010010
B (Blue) Inline Low Fluid
Tem p.
146 D T 1 B 1
10010011 A (Red) Hose Low Fluid Temp. 147 D T 1 A 2
Fault Code
Bit Pattern
(Bit 7 --> Bit 0)
Error String
Error
Number
Error Code
Shown on the
ADM
