User's Manual

Parts
94 333347F
HM25 Melter and Pump, 24V169
HM50 Melter and Pump, 24V542
--- Not for sale.
Available kits (purchase separately):
Ref. Part Description Qty.
201 ---
BASE, melter, HM50
1
---
BASE, melter, HM50
1
202✖ ---
TANK, melter, HM50
1
---
TANK, melter, HM25
1
203• ---
MANIFOLD, outlet
1
204✖ ---
PLATE, mounting; HM50
1
---
PLATE, mounting; HM25
1
205 ---
HOUSING, fire rod; HM50
1
---
HOUSING, fire rod; HM25
1
206• 111317
RING, retaining, int.
3
207✖ 16W615
O-RING, fluoroelastomer;
(HM50 only)
1
126475
O-RING, fluoroelastomer;
(HM25 only)
1
208 24V522
BAND, heater; HM50 only
1
24R039
BAND, heater; HM25 only
1
209• 24R037
HEATER, rod,1500 watts; HM50
1
24R034
HEATER, rod, 500 watts; HM25
1
210 24R036
HEATER, rod,1000 watts; HM50
2
24R037
HEATER, rod,1500 watts; HM25
2
211✖ 116940
SCREW, cap,sh,5/16-18
7
213 ---
SCREEN, wire
1
214• 112855
PACKING, o-ring
1
215
---
PLUG, o-ring boss
1
216ॠ---
SLEEVE, cylinder
1
217†‡• 108526
PACKING, o-ring, ptfe
2
218 24V558
MOTOR, double ended, air; see
page 95
1
219 ---
PLATE, pump adapter
1
220 ---
ROD, tie, 1.5 in. stroke
3
221• 192624
GUIDE, ball
1
222†◆• 239932
VALVE, piston
1
223◆• ---
ROD, piston
1
224†◆• 105444
BALL, (.31250)
1
225†◆• ---
SEAL, u-cup, piston
1
226†◆• ---
BEARING, piston
1
227†• 105445
BALL, (.5000)
1
228†• 192642
SEAT, carbide
1
229†• 107079
PACKING, o-ring
1
230• ---
HOUSING, foot valve
1
231†• 105802
O-RING
1
232†• 113944
PACKING, o-ring
1
233†• ---
BEARING, throat
1
234†‡• ---
SEAL, u-cup, throat
1
235• 193046
NUT, packing
1
236•
24P855
FILTER, assy, 100 mesh, welded
1
238 196762
PIN, straight
1
239 196750
SPRING, retaining
1
240 101864
SCREW, cap, sch; 5/16 x 1 in.
3
242★• 117059
O-RING, fluoroelastomer
1
243★• ---
RETAINER, seat, dump valve
1
244★• 15Y627
PACKING, o-ring #2-116, ptfe
1
245★• ---
VALVE, relief
1
246• 121295
SCREW, cap, socket head; 5/16 x
2.5 in.
4
247• 15H304
FITTING, plug 9/16 sae
9
249 167002
INSULATOR, heat
10
251
✿ •
24R040
SWITCH, overtemperature
1
252• ---
INSERT, helical
7
253✖ ---
PLATE, melter; HM25 only
1
---
PLATE, melter; HM25 only
1
254 ---
O-RING, -910
1
255
✿ •
107388
SCREW, mach, pnh;
#4 x 3/8 in.
2
257 ---
BRACKET, shelf; HM50 only
1
---
BRACKET, shelf; HM25 only
1
258 ---
GROMMET, 1/4 ID
1
259 110298
SCREW, cap, sch,
1/4 x 7/8 in. ;
HM50 only
4
115506
SCREW, mach, hex wash hd, 1/4 x
3 in.; HM25 only
4
268 115814
WASHER, flat, sst; HM50 only
4
Kit Description Includes
24P852† Pump repair 217, 222, 224, 225, 226, 227,
228, 229, 231, 232, 233, 234,
and seal installation tool
15B661.
24P853‡ Cylinder 216, 217, 234, and seal instal-
lation tool 15B661.
24P854◆ Pump rod 222, 223, 224, 225, 226
24P856★ Pressure relief
valve
242, 243, 244, 245
24V508✖ Melter 202, 204, 207, 211, 253, and
insulator (53). See InvisiPac
Systems parts starting on
page 83 for insulator (53)
identification.
24R040
✿
RTD 125, 251, and 255. See Elec-
trical Enclosure on page 89.
24R709 • Assembled pump
manifold
203, 206, 209, 214, 216, 217,
221, 222, 223, 224, 225, 226,
227, 228, 229, 230, 231, 232,
233, 234, 235, 236, 242, 243,
244, 245, 246, 247, 251, 252,
255
--- Special tools See Special Tools on page
100.
Ref. Part Description Qty.
