User's Manual

Parts
333347F 87
39 --- GROMMET, 1/4 ID
111111111111111111
40 --- BUSHING, strain relief
222222222222222222
41 --- GROMMET, tube
111111111111111111
42 --- GROMMET, tube
111111111111111111
43▲ 16Y781 LABEL, safety
111111111111111111
44 16U007 LABEL, InvisiPac, HM25
111111111
--- LABEL, InvisiPac HM50
111111111
45 --- LABEL
111111111111111111
47✖ 24P859 KIT, fuses, board, temp con-
trol
111111111111111111
48✖ 24P176 KIT, i/o connector
111111111111111111
49 125871 TIE, cable, 7.50 in.
10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10
50❄ 24R324 TOKEN, software
111111111111111111
53‡ 16W659 INSULATOR, melter
111111111
16T677 INSULATOR, melter
111111111
54 --- NUT, bushing
222222222222222222
57 123554 COUPLER, 3/8 in. OD tubing
111111111111111111
58 24A326 BRACKET, mounting,
assembly
111111111111111111
61† --- FUNNEL, large mouth
111111111111111111
62† --- BAFFLE, pellet
111111111111111111
63 121487 GROMMET, sheet metal, 3/4
in.
222222222222222222
64 24R707 KIT, inlet, air
111111111111111111
66† --- FUNNEL, insert
111111111111111111
67† 24V506 FILTER, HM50 feed
111111111111111111
68† --- FUNNEL, filter cover
111111111111111111
69† --- O-RING, fluoroelastomer,
160
333333333333333333
72 110932 CONNECTOR, male
111111111111111111
73† --- HOUSING, sensor, HM50
111111111111111111
74† --- SCREW, #10-16, thread
forming
555555555555555555
75 16T675 INSULATOR, melter mani-
fold
111111111
16W671 INSULATOR, melter, mani-
fold
111111111
76 --- FITTING, tee, 1/8npt x 3/8t x
3/8t
111111111111111111
77 --- RESTRICTOR, air, 0.0225
in. orifice
111111111111111111
78 198177 FITTING, push, straight
111111111111111111
79★ 24W001 ADAPTER, HM25
111111111
24W000 ADAPTER, melter HM50
111111111
Ref Part Description
Quantities
HM50 HM25
2 Channel 4 Channel 6 Channel 2 Channel 4 Channel 6 Channel
24T918
24V201 24V198
24T919
24V202 24V199
24T920
24V203 24V200 24V423 24V429 24V426 24V424 24V430 24V427 24V425 24V431 24V428
