User's Manual

Component Identification
12 333347F
Heated Fluid Manifold
Key:
T Electrical Enclosure Front Access Door
UMelter
W1 Drain Port
W2 Drain Tray
X Inlet Filter (Low Pressure - Before Pump)
Y Outlet Filter (High Pressure - After Pump)
Z Adhesive Pellets Level Sensor (not shown; inside funnel)
AA Power and RTD Harness Connection to Heated Hose and
Applicator (harness connects from system to heated hose
then from heated hose to applicator)
AB Inlet Funnel Screen
F IG . 2
WLD
U
R
W1
Y
X
AA
AB
NOTE: System shown with plastic and metal shrouds removed.
W2
T
