User's Manual

Technical Specifications and Ordering Information
Name of Pump Senator 19:1 Viscount II 1900 Bulldog 31:1 Viscount II 3100
Lower size 800 800 800 800
Maximum fluid pressure 1900 psi (131 bar, 13.1 MPa) 1900 psi (131 bar, 13.1 MPa) 3100 psi (213 bar, 21.3 MPa) 3100 psi (213 bar, 21.3 MPa)
Maximum motor inlet pressure 100 psi (air) (6.9 bar, 0.69 MPa) 450 psi (oil) (31 bar, 3.1 MPa) 100 psi (air) (6.9 bar, 0.69 Mpa) 750 psi (oil) (51.7 bar, 5.1 MPa)
Flow rate @ 60 cpm 2.8 gpm (10.6 lpm) 2.8 gpm (10.6 lpm) 2.8 gpm (10.6 lpm) 2.8 gpm (10.6 lpm)
Cfm or gpm required per gallon 24 cfm 4.3 gpm (16.2 lpm) 32 cfm 4.3 gpm (16.2 lpm)
Fluid pump outlet size 1” npt (f) 1” npt (f) 1” npt (f) 1” npt (f)
Motor inlet size 3/4” npt (f) 3/4” npt (f) 3/4” npt (f) 3/4” npt (f)
Weight of pump 160 lb (73 kg) 177 lb (80 kg) 160 lb (73 kg) 177 lb (80 kg)
Instruction manual 308351 308351 308351 308351
Bin Supply Senator 19:1 Viscount II 1900 Bulldog 31:1 Viscount II 3100
Pump 246941 246938 246940 246938
Air controls: FRL, 1/2” 217072 217072
Air run away control, 3/4” 224040 224040
Air speed control, 1/2”(f) 510441 510441
Floor stand (3” inlet) 222780 222780 222780 222780
Hydraulic controls* 236865 236865
Outlet hydraulic hose connector
1”(m) x 1-1/2”(f), 1500 psi rated
Not included Not included
55-Gallon Drum Supply Senator 19:1 Viscount II 1900 Bulldog 31:1 Viscount II 3100
Ram package with pump 234377 234378 234374 234378
Air run away control, 3/4” 224040 224040
Air speed control, 1/2” 510441 510441
Hydraulic controls* 236865 236865
Outlet hydraulic hose connector
1”(m) x 1-1/2”(f), 1500 psi rated
Not included Not included
Misc. Information Senator 19:1 Viscount II 1900 Bulldog 31:1 Viscount II 3100
Pump lower section 246939 246939 246939 246939
Ram plate replacement seals 165601 165601 165601 165601
*Hydraulic controls include hydraulic flow and pressure control, ball valves, 3 ft supply and return hose
19:1 Senator 19:1 Senator on
55 gallon ram
31:1 Bulldog Viscount II 3100 on
55 gallon ram
8
