Installation & Assembly

PART NO

FIGURE

DESCRIPTION

Q'TY

Chair Back

Wood Seat With Frame

PARTS LIST

1 Pce

Front Leg (Left)

1 Pce

2 Pcs

Caution: Please read instruction thoroughly before unpacking assembly parts. Sharp exposed staple tips

can cause injury, therefore, for your protection, please remove any exposed staples used in packing.

Please keep all hardware parts out of reach of children.

1.We recommend that you should assemble this product with the assistance of another person;

this will make assembly easier, and will help to eliminate damage to the product or injury to

persons during assembly.

2.Be sure to check all packing materials carefully for small parts that may have come loose inside

the carton during shipment.

3.Please do not over tighten screws or bolts. Reminder

1.use only the hardware supplied.

2.Do not over-tighten the bolts.

3.This item may require periodic tightening.

RAKE BACK BARSTOOL

Hardware Bag

Front Leg (Right)

1 Pce

Side Stretcher (Right / Left)

Front Stretcher (Short)

Page 1 of 2

MADE IN MALAYSIA

PAGE 1
RAKE BACK BARSTOOL Caution: Please read instruction thoroughly before unpacking assembly parts. Sharp exposed staple tips can cause injury, therefore, for your protection, please remove any exposed staples used in packing. Please keep all hardware parts out of reach of children. 1.We recommend that you should assemble this product with the assistance of another person; this will make assembly easier, and will help to eliminate damage to the product or injury to persons during assembly. 2.
PAGE 2
RAKE BACK BARSTOOL HARDWARE PARTS : 8x1.1/4" Pan Head Screw 6 pcs M6x40mm JCBC Bolt 2 pcs M6x70mm JCBC Bolt 8 pcs M6x13mm Lock Washer 10 pcs M6.5x16.5mm Flat Washer 10 pcs Allen Key 1 pce Glue 1 pce ASSEMBLY: 1. Attach the Wood Seat with Frame to the Chair Back using the provided hardware as shown in Fig 1. 2.Attach side Stretcher (Left/Right) to Chair back using the provided hardware as shown in Fig 2.2. Attach Front Stretcher to front legs using the provided hardware as shown in Fig.2.
