User guide
Table Of Contents
- 1 Applications
- 2 Operation
- 2.1 Battery Test
- 2.2 Taking Measurements
- 2.3 Special Functions
- 2.4 Overload Display
- 2.5 Switching the Measuring Instrument Off
- 2.6 Measuring Luminance (accessory required)
- 2.7 Tips for Taking Correct Measurements
- 2.8 Ever-Ready Case
- 3 Accessories
- 4 Technical Data
- 5 Maintenance and Calibration
- 6 Illumination Regulations
- 7 For Lighting and Illumination Technicians
- 8 Fundamental Light Theory
- 9 V(l) Matching
- 10 Product Support
- 11 Repair, Replacement Parts and Calibration Service
GOSSEN Foto- und Lichtmeßtechnik GmbH 9
Measuring Rate approx. 2.5 measurements
per second
Digital Display
LCD Field 50 mm x 25 mm
Display 7 segment
Char. Height 13 mm
Digits 3½ places
Overload Display “OL.” is displayed
Power Supply
Battery 1.5 V mignon alkaline-
manganese cell per IEC LR 6
Service Life approx. 75 hours continuous
operation, equivalent to
approx. 2500 measurements
Battery Test Automatic display of “ ”
symbol when battery voltage
drops to below approx. 1.0 V
Electromagnetic Compatibility (EMC)
Interf. Emission EN 50081-1: 1992
Interf. Immunity EN 50082-1: 1992
Mechanical Design
Housing Plastic
Dimensions Meter: 65 x 120 x 19 mm
(without ever-ready case)
Sensor: 31 x 105 x 30 mm
Weight Meter and sensor:
approx. 200 gr. w/o battery
Light Detector Light collector surface
at diffuser: approx. 20 mm dia.
Cable from Meter
to Sensor MAVOLUX 5032C: cable coil,
available with extension
MAVOLUX 5032B: cable coil,
permanently attached
Cable Length approx. 1.5 m
Technical Data, Accessories
Luminance Attachment (meas. angle
ε
1
/
10
= 20° )
