Characteristics MAVOLUX 5032B

Most Important Error Limits MAVOLUX 5032B

Light Detector silicon photodiode with

V(

λ) filter per DIN 5032 part 7,

class B

Error Limits per DIN 5032, part 7, class B

Meas. Quantity Measuring Range Resolution

in lx

Resolution

in fc

in Lux (lx) in footcandles (fc)

Illumination I 0.01

… 19,99 0.001 … 1.999 0.01 0.001

I I 0.1

… 1 99,9 0.01 … 19.99 0.1 0.01

III 1

… 19 99 0,1 … 1 99.9 1 0.1

I V 10

… 19 990 1 … 19 99 10 1

in Candela/m² (cd/m²) in footlambert (fL) in cd/m² in fL

Luminance

(with luminance

attachment

for cd/m

2

or fL)

I0.1

… 199.9 0.01 … 19.99 0.1 0.01

II 1

… 1 999 0.1 … 199.9 1 0.1

I I I 10

… 19 990 1 … 1 999 10 1

I V 100

… 199 900 10 … 19 990 100 10

Characteristics Allowable Error

Limits per

DIN 5032 Class B

Actual Error

MAVOLUX 5032B

V(

λ) Matching 6% 3%

True Cosine Evaluation 3% 2%

Linearity 2% 1%

Adjustment Error 1% 0,8%

Total Error 10% 8%
