GOSSEN Foto- und Lichtmeßtechnik GmbH 7

4 Technical Data

Characteristics MAVOLUX 5032C

Most Important Error Limits MAVOLUX 5032C

Light Detector silicon photodiode with

V(

λ) filter per DIN 5032 part 7,

class C

Error Limits per DIN 5032, part 7, class C

Meas. Quantity Measuring Range Resolution

in lx

Resolution

in fc

in Lux (lx) in footcandles (fc)

Illumination I0.1

… 199,9 0.01 … 19.99 0.1 0.01

II 1

… 1 999 0,1 … 199.9 1 0.1

III 10

… 19 990 1 … 1 999 10 1

I V 100

… 199 900 10 … 19 990 100 10

in Candela/m² (cd/m²) in footlambert (fL) in cd/m² in fL

Luminance

(with luminance

attachment

for cd/m

2

or fL)

I1

… 1 999 0.1 … 199.9 1 0.1

I I 10

… 19 990 1 … 1 999 10 1

III 100

… 199 900 10 … 19 990 100 10

I V 1 000

… 1 999 000 100 … 199 900 1000 100

Characteristics Allowable Error

Limits per

DIN 5032 Class C

Actual Error

MAVOLUX 5032C

V(

λ) Matching 9% 7.5%

True Cosine Evaluation 6% 2%

Linearity 5% 1.5%

Adjustment Error 2% 1%

Total Error 20% 15%
