Operation Manual

12 GMC-I Messtechnik GmbH
We are pleased to perform DKD or factory calibrations for you in our
calibration laboratory. Please visit our website at
www.gossenmetrawatt.com (→ Services → DKD Calibration Center
or → FAQs → Calibration questions and answers).
By having your measuring instrument calibrated regularly, you fulfill
the requirements of a quality management system per
DIN EN ISO 9001.
5.5 Device Return and Environmentally Compatible Disposal
The instrument is a category 9 product (monitoring and control
instrument) in accordance with ElektroG (German Electrical and
Electronic Device Law). This device is not subject to the RoHS
directive.
We identify our electrical and electronic devices (as of
August 2005) in accordance with WEEE 2002/96/EG and
ElektroG with the symbol shown to the right per DIN EN
50419.
These devices may not be disposed of with the trash. Please contact
our service department regarding the return of old devices.
If you use batteries or rechargeable batteries in your instrument or
accessories which no longer function properly, they must be duly
disposed of in compliance with the applicable national regulations.
Batteries or rechargeable batteries may contain harmful substances
or heavy metal such as lead (PB), cadmium (CD) or mercury (Hg).
They symbol shown to the right indicates that batteries or
rechargeable batteries may not be disposed of with the
trash, but must be delivered to collection points specially
provided for this purpose.
6 Characteristic Values
Insulation Resistance Measurement, Measuring Voltages: 100 / 250 / 500 V
* Measuring error under reference conditions relative to scale length (l = 84.6 mm)
Low-Resistance Measurement, Measuring Voltage: 4.5 V
* Measuring error under reference conditions relative to upper range value (l = 74.9 mm)
Voltage Measurement, DC / AC (40 … 200 Hz)
* Measuring error under reference conditions relative to scale length
(l = 73.3 mm)
Measuring Range Intrinsic
Uncertainty
Overload Measuring
Current
Short-Circuit
Current
0.1 … 400 MΩ 2.5% * 600 V AC > 1 mA < 10 mA
Measuring Range Intrinsic
Uncertainty
Overload Measuring Current
0 … 4 Ω 2.5% * 250 V DC >200 mA
Measuring Range Intrinsic
Uncertainty
Overload Internal Resistance
0 … 500 V 2.5% * 600 V AC 450 kΩ
Pb Cd Hg
