CH 3/ View Real Time Data
Distortion meter
list (continued)
Distortion Tab Parameter Name Label
TIF
(for A, B, C, D)
Voltage Telephone Influence Factor
Fundamental
V TIF fund
Current Telephone Influence Factor
Fundamental
I TIF fund
Voltage Telephone Influence Factor
RMS
V TIF RMS
Current Telephone Influence Factor
RMS
I TIF RMS
Telephone Influence Factor Product TIF Prod
Crest Factor
(for A, B, C, D)
Voltage Crest Factor Volts Crest Factor
Current Crest Factor Amps Crest Factor
Power
(for A, B, C, D)
Signed Phase Harmonic Power Signed
Unsigned Phase Harmonic Power Unsigned
Transformer
(for A, B, C, D)
Transformer Derating Factor Derating Factor
K Factor K Factor
