3-7
CH 3/ View Real Time Data
Standard meter
list (continued)
Standard Tab Parameter Name Label
Demand Active Power Demand Active Power Demand
Apparent Power Demand Apparent Power Demand
Reactive Power Demand Reactive Power Demand
RMS Current Demand Phase A RMS Current Demand Ph A
RMS Current Demand Phase B RMS Current Demand Ph B
RMS Current Demand Phase C RMS Current Demand Ph C
RMS Current Demand Average RMS Current Demand Avg
Energy
(for A, B, C, D,
Total)
Watt Hours Watt Hrs
Volts Ampere Hours VA Hrs
Volts Ampere Reactive Hours VAR Hrs
Harmonics
(for A, B, C, D)
Voltage Total Harmonic Distortion V THD
Current Total Harmonic Distortion I THD
Harmonic Power Unsigned Harm Pwr Unsigned
Advanced
Energy (for A,
B, C, D, Total)
Forward Fundamental Frequency
Watt H ours
Fwd Whr
Forward Fundamental Frequency
Volts Ampere Reactive Hours
Fwd VAR Hr
Reverse Fundamental Frequency
Watt H ours
Rev Whr
Reverse Fundamental Frequency
Volts Ampere Reactive Hours
Rev VAR Hr
