D-1
APPENDIX D
User Replaceable Parts List
Introduction
The following parts are easily replaced by the operator and do not require special tools
or access to the interior of the unit.
To order parts
Call Dranetz-BMI Customer Service at (732) 287-3680 or 1-800-372-6832 to order any
of the following parts.
Parts List
Measurement
cable set, parts
list
Part Description Part Number
AC Adapter/Battery Charger XBC-PX5
Battery Door 116037-G1
Battery Pack BP-PX5
Rubber Skin for Energy Platform 116035-G4
Voltage Cable Assembly, 4 Pair w/ Alligator Probes
(See below for separate parts)
116042-G6
Part Description Quantity Part Number
Interconnect Measurement Channel Cable Assembly 1 114013-G1
Carry Strap 1 116040-G1
Cable Pouch, PP4300 1 116043-G1
Red Silicone Cable, 4MM Plug, 1000V 1 900366
Yellow Silicone Cable, 4MM Plug, 1000V 1 900367
Blue Silicone Cable, 4MM Plug, 1000V 1 900368
Grey Silicone Cable, 4MM Plug, 1000V 1 900369
White Silicone Cable, 4MM Plug, 1000V 2 900370
Alligator Clip, 4MM Plug-on, Red 4 900371
Alligator Clip, 4MM Plug-on, Black 2 900372
