Instructions / Assembly

Table Of Contents

8" MINIMUM

(NOT MOUNTED)

GLIDER SWING

(CHAINS)

ROPES

SWING BEAM

(SWING LEG)

SUPPORT POLE

GLIDER BRACKET

ADJUSTABLE

GLIDER BRACKET

ADJUSTABLE

SWING

A = 0.04 (H) + B

SECOND BRACKET USING THE FOLLOWING FORMULA:

2: CALCULATE THE DISTANCE BETWEEN THE FIRST ADJUSTABLE GLIDER BRACKET AND THE

GLIDER BRACKET TO BEAM

STEP 3: MOUNTING THE ADJUSTABLE

TOP OF THE BEAM.

1: PLACE THE ADJUSTABLE GLIDER BRACKET (1) AND ADJUSTABLE GLIDER BRACKET (2) OVER THE

A = THE CENTER TO CENTER

DISTANCE BETWEEN

UPPERMOST SUSPENSION

POINTS OF THE

SWING ASSEMBLY.

B = THE CENTER TO CENTER

DISTANCE BETWEEN THE

SWING SEAT ATTACHMENT

POINTS.

H = THE DISTANCE BETWEEN

THE UPPERMOST

SUSPENSION POINT AND

THE PROTECTIVE

SURFACING.

ADJUSTABLE GLIDER

BRACKET (2)

ADJUSTABLE GLIDER

BRACKET (1)

(

)
