REPLACEMENT PARTS LIST
10
Part Description Quantity
Dump Lock Assembly 1
Rear Strut 2
Rear Frame 1
Rear Axle Assembly 1
Front Frame 1
Front Strut 2
Front Axle Assembly 1
Wheel 4
Handle 1
Hardware Kit
(see Hardware Contents for details) 1
B
C
D
E
F
G
H
I
J
K
OPERATION INSTRUCTIONS
STAKE OUT SIDES
To increase the cubic foot
capacity of this item, these 8
pockets can be used to fit
stake out side panels as
shown. Actual pocket
dimensions: 0.75in x 2.5in
as shown in Fig. 1.
Fig. 1
For replacement parts, visit us online at www.gorillacarts.com to fill out a
replacement parts submission form or call our customer service department at
1-800-867-6763, 9 a.m. - 4 p.m., CST, Monday-Friday
