PRODUCT IDENTIFICATION
6
MODEL # MFG. # 80 % GAS FURNACES
AMS8
AMS80403AXAA
AMS80603AXAA
AMS80604BXAA
AMS80804BXAA
AMS80805CXAA
AMS81005CXAA
AMS81205DXAA
AMS81405DNBA
Amana Brand 80% gas furnace, 33 3/8" tall, upflow, horizontal right of left installation positions.
Induced draft, two-tone gray cabinet and panels. Multi-speed PSC motor, 120 volt carbide mini Igniter
with integrated circuit board. Left or right side gas entry. Stainless steel tubular heat exchanger.
Standard altitude rated to 5,500 ft. Firing rate of 20,000 BTUH per burner, #45 gas orifices. Chassis
widths 14",17.5", 21", 24.5"
AMS8
AMS80403AXAB
AMS80603AXAB
AMS80604BXAB
AMS80804BXAB
AMS80805CXAB
AMS81005CXAB
AMS81205DXAB
AMS81405DNBB
Amana Brand 80% gas furnace, 33 3/8" tall, upflow, horizontal right of left installation positions.
Induced draft, two-tone gray cabinet and panels. Multi-speed PSC motor, 120 volt carbide mini Igniter
with integrated circuit board. Left or right side gas entry. Stainless steel tubular heat exchanger.
Standard altitude rated to 5,500 ft. Firing rate of 20,000 BTUH per burner, #45 gas orifices. First rev
with W hite-Rodgers gas valve. Chassis widths 14",17.5", 21", 24.5"
MODEL # MFG. # 80 % GAS FURNACES
ADSS8
ADSS800403AXAA
ADSS800603AXAA
ADSS800804BXAA
ADSS801005CXAA
Amana Brand 80% gas furnace, 33 3/8" tall, dedicated downflow installation. Induced draft, two-tone
gray cabinet and panels. Multi-speed PSC motor, 120 volt carbide mini Igniter with integrated circuit
board. Left or right side gas entry. Stainless steel tubular heat exchanger. Standard altitude rated to
5,500 ft. Firing rate of 20,000 BTUH per burner, #45 gas orifices. Chassis widths 14",17.5", 21".
ADSS8
ADSS800403AXAB
ADSS800603AXAB
ADSS800804BXAB
ADSS801005CXAB
Amana Brand 80% gas furnace, 33 3/8" tall, dedicated downflow installation. Induced draft, two-tone
gray cabinet and panels. Multi-speed PSC motor, 120 volt carbide mini Igniter with integrated circuit
board. Left or right side gas entry. Stainless steel tubular heat exchanger. Standard altitude rated to
5,500 ft. Firing rate of 20,000 BTUH per burner, #45 gas orifices. First rev with W hite-Rodgers gas
valve. Chassis widths 14",17.5", 21".
