* All installas above 7,000 ft. require a pressure switch change.
For installations in Canada, the GME8 furnace is certified only to 4,500 ft.
* Negative pressure readings are in inches of water column (*w.c.)
Part Number 20162903
Open Setting (°F)
160
GME80703BXC*
1
GME80905CXC*
1
GME81155CXC*
1
PRIM ARY LIMIT
Part Number B1370145
Open Setting (°F)
300
GME80703BXC*
1
GME80905CXC*
1
GME81155CXC*
1
ROLLOUT LIMIT SWITCHES
MODEL
TRIP POINT
ID BLOWER
PRESSURE
SWITCH
ID BLOWER
PRESSURE
SWITCH
PART #
GME80703BXC*
-0.70 B1370158
GME80905CXC*
-0.75 B1370179
GME81155CXC*
-1.40 B1370156
PRESSURE SWITCH TRIP POINTS
AND USAGE CHART
Part Number 0130F00038
Open Setting (°F)
120
GME80703BXC*
1
GME80905CXC*
1
GME81155CXC*
1
AUXILIARY LIMIT SWITCHES
