The Countdown timer is programmed in increments of 5 minutes from “0:00” to a maximum of “21:00”.

When “0:00” is programmed, the countdown timer is disabled and the output will be manually controlled.

When a countdown timer is greater than “0:00”, pressing the appropriate output button will turn the output

on and start the timer. When the programmed time has elapsed, the output will automatically turn off.

This will determine the normal hours of filtration for the pool. For pool/spa combination

systems with spillover enabled, the valves will automatically switch to spillover mode at the

start of the filtration period. For all other systems, the valves will switch to the pool-only

position. Refer to page 8 for general notes regarding timeclock programming.

If you have a 2-speed pump, this setting will be the period of time when the pump runs at high

speed. There is a separate timeclock for the low speed operation (see below). If the high

speed and low speed periods overlap, then the pump will operate in low speed during the

overlap period.

There are several reasons the filter pump may be running at times other than the timeclock

period set above. These include super-chlorination, spa operation, manual operation, heater

cooldown, freeze protection and “solar-extend”.

This menu item is only available if you have a 2-speed pump (Configuration Menu). This

timeclock will set the normal time period for filter pump low speed operation. If the filter pump

was off prior to the start of this time period, the filter pump will first turn on at high speed for

3 minutes to prime and establish water flow. Afterwards, it will drop down to low speed for

the remainder of the programmed low speed time period. While this time clock will override

the high speed timeclock (see above), there are several reasons why the pump will

automatically switch to high speed operation during this programmed time period. These

include manual operation, spa operation, or solar heating operation. Refer to page 9 for

general notes regarding timeclock programming.

This menu is only available if the system has been setup for “spa only” or “pool and spa”.

During the programmed spa time, the Aqua Logic will turn on the filter pump and move the

pool/spa valves into the “spa-only” position. The heater will automatically heat the spa up

to the programmed spa temperature (see page 7). This programmed spa operation will take

Set Day and Time

Wednesday 10:37P

Adjust time setting

Move between start and stop times & to previous/next menu item

Lo spd-all days

8:30A to 4:00P

Adjust time s

Lo spd-weekends

8:30A to 4:00P

Lo spd-weekdays

8:30A to 4:00P

Adjust time setting

Move between start and stop times & to previous/next menu item

Set Day and Time

Wednesday 10:37P

Adjust time setting

Move between start and stop times & to previous/next menu item

Filter-all days

8:30A to 4:00P

Adjust time s

Filter-weekends

8:30A to 4:00P

Filter-weekdays

8:30A to 4:00P

Adjust time setting

Move between start and stop times & to previous/next menu item

Set Day and Time

Wednesday 10:37P

Adjust time setting

Move between start and stop times & to previous/next menu item

Spa-all days

6:00P to 9:00P

Adjust time s

Spa-weekends

6:00P to 9:00P

Spa-weekdays

6:00P to 9:00P

Adjust time setting

Move between start and stop times & to previous/next menu item
