IMPORTANT:

• ALLINSTALLATIONWORKSHOULDBEDONEBYACCREDITEDPROFESSIONAL.

• SHUTOFFPOWERSUPPLYATFUSEORCIRCUITBREAKER!

• USEONLYTHESPECIFIEDBULBS.DONOTEXCEEDTHEMAXIMUMWATTAGE!

AssemblyInstructions:9808-SF (Seaport)

CLEANING TIPS

Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the

xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture. Hand wash the glass with warm water and

mild detergent. Dry with a lint-free or microber cloth.

PREPARING FOR INSTALLATION

1.Takethemountingstrapassemblyfromthepartsbag.

Mountingstrap(B)containsseveralthreadedholes.Twoof

mountingscrews(A)shouldbeattachedtomountingstrap

(B).Youmayneedtotightennuts(C)thatholdthesescrewsin

place.Ifthescrewsarenotattached,pleaseholdcanopy(F)

uptomountingstrap(B).Lineuptheholesincanopy(F)with

theholesinmountingstrap(B)andinsertmountingscrews(A)

intomountingstrap(B)sothatmountingscrews(A)protrude

throughtheholesincanopy(F).Mountingscrews(A)arelong,

sopleasetestthecanopyagainstthemountingstraptosee

howfaryoushouldinsertthescrews.Tightennuts(C)onto

mountingscrews(A)toholdthescrewsinplace.

2.Placemountingstrap(B)overthejunctionboxandsecure

inplacewithmountingscrews(D).Tightenthescrews

securelywithascrewdriver.

How to Identify the Fixture’s Wires

Hot Neutral Ground

Smooth

Ribbed

Bare Metal,

Green, or

Green Inner

Thread

Black

White

Black Inner

Thread

White Inner

Thread

House Wires

Fixture Wires

Hot

For Customer Service, please

contact the place of purchase.

FINISHING THE INSTALLATION

4.Pushcanopy(F)uptotheceilingandtightlythreadnuts(H)ontotheexposedthreadsofmountingscrews(A).

5.Installlightbulb(notprovided)basedonthexture’sspecications.Donotexceedthemaximumwattage.

6.Slidemetalcage(N)uptothebottomofcap(P).Securethemetalcagesinplacewiththeremainingdecorativenuts(H).

Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.

CONNECTING THE WIRES

3.Haveanassistantsupportthexture’sweightwhilecompletingthewiring.

Refertothewiringdiagramandattachthexture’swirestothepowersupply

wiresfromthejunctionbox.ConnectHottoHot,NeutraltoNeutral,and

GroundtoGround.Twisttheendsofthewirepairstogether,andthentwist

onawireconnector.Makesurealltwistsareinthesamedirection.Ifthereis

nohousegroundwirecomingfromthejunctionbox,locategroundscrew(E)

onthemountingbracket/mountingstrapandwrapthexture’sgroundwire

aroundthegroundscrew.Useascrewdrivertotightenthetopofgroundscrew

(E)ontothewiresandintothemountingbracket/mountingstrap.Tuckthe

wiresintothejunctionbox.

Remove all of the contents from the carton. See the important notes above. Shut off the power at the circuit breaker and

completely remove the old xture from the ceiling, including the old mounting strap.
