User Manual

GP-PWM-30
________________________________________________________________________
5
1.2 Specifications
Description
Value
Dimensions (H x W x D):
107 x 190 x 35 mm
4.25 x 7.5 x 1.38 in
Weight: 172 grams
6 oz
Maximum Wire Gauge: #6 AWG
Warranty: 5 years
• PWM Charging
• 3 Battery Charging profiles
• 4 Stage Charging
• Monthly Equalize option
• Displays Charging Current,
Battery Voltage and Battery
State of Charge
• Reverse Polarity protected
• Temperature Compensated
• RoHS Compliant,
environmentally safe
• Accepts up to 495 watts of
solar at 12 volts
• Maximum Power Boost
Technology
Nominal System Voltage
12V
Max. Solar Array Current
30 amps
Battery Voltage Range
6V – 15.5V
Max. Solar Voltage
28V
Operating Consumption
Display Consumption
6mA
10mA
Bulk/Absorption Voltage 14.1/14.4V
(25°C / 77°F), 1 - 2h / Day
Float Voltage
13.7 (25°C / 77°F)
Equalization Voltage 14.8V (25°C / 77°F),
2h / 28 Day or V < 12.1
Temperature
Compensation
- 4mV/cell*K
Operating Temperature
Display Operating
Temperature
- 40 to 85°C / - 40 to 185°F
- 20 to 55°C / - 4 to 131°F
Humidity
99% N.C.
Protection Battery Reverse Polarity,
Solar Array Reverse Polarity,
Over Temperature, PV Short
Circuit, Over Current
The total rated Maximum Power Current (Imp) of the PV
input should not exceed 30 Amps.
The GP-PWM-30 will limit PV current above 30 Amps.
Although the GP-PWM-30 will accept PV current greater
than 30 Amps for a short duration, damage may occur if the
GP-PWM-30 operates continuously with greater than 30
Amps of PV input.
