Battery Charge Profile Chart
Auto Equalize: The GP-PWM-30 has an automatic equalize feature that
will charge and recondition your batteries once a month at a higher
voltage to ensure that any excess sulfation is removed. This feature is
recommended for Flooded batteries only. Check with your battery
manufacturer.
IMPORTANT: This feature is only available for wet cell or flooded
batteries (Charging Profile 1).
Battery Type
FLOODED
AGM
GEL
Charging Profile #
1
2
3
Float Charge @ 25°C:
13.7V (+/- 0.1V)
Bulk/Absorption Charge @ 25°C:
Applied for 1h each morning
14.4V (+/- 0.1V)
14.1V
(+/- 0.1V)
Boost Charge
Applied for 2 hours if the battery voltage drops
below 12.3 volts.
14.4V (+/- 0.7V)
14.1V
(+/- 0.1V)
Equalization Charge
Applied for 2 hours every 28 days and if the
battery voltage drops below 12.1 volts.
14.8V
(+/-0.1V)
N/A N/A
The Boost Charge will occur in addition to the Bulk Charge. The Equalization Charge will
occur in addition to the Boost Charge.
If a charging cycle is unable to complete in a single day, it will continue the following day.
The terms FLOODED, AGM and GEL are generic battery designations. Choose the
charging profile that works best with your battery manufacturer’s recommendations.
