Manual

20 Slide lock spring
21 Slide lock
22 Locking block
23 Trigger mechanism housing with ejector
24 Connector
25 Trigger spring
25a New York trigger spring
25b New York trigger spring plus
26 Trigger with trigger bar
27 Slide stop lever
28 Trigger bar
29 Trigger housing pin
30 Follower
31 Magazine spring
32 Magazine floor plate
32a Magazine insert
33 Magazine tube
34 Locking pin for non 9mm GLOCK pistols
(Table No. 1)
Above components part numbers are referring to the exploded drawing.
Note: A modified version of the Recoil spring/Recoil tube has been introduced in 1991 and is
supplied then only as one complete Recoil spring assembly which must not be dismounted.
Earlier supplied Recoil springs and tubes can certainly remain in use without problem.
Except for the following listed components, all other components are interchangeable with the
GLOCK 17.
Parts not interchangeable with the GLOCK 17:
GLOCK 17L GLOCK 19
No. 1, 2, 19, 24 1, 2, 3, 17, 20, 22, 26, 27, 31, 33
(Table No. 2)
For corresponding denomination of component parts please refer to table no.1
