FUNCTION OF THE WAEPON
1) State of the weapon: loaded, i.e., a round in the barrel, firing pin (5) partially tensioned and
secured, trigger (26), in the foremost position. the trigger safety integrated in the trigger is actuated
with the trigger finger in order to pull the trigger all the way.
2) When the trigger slack is taken up to the first pressure point (travel 5mm) the weapon is released
from safety, i.e. the trigger bar lies behind the safety ramp, the firing pin is under tension. As the
trigger is pulled further back, the trigger bar releases the firing pin by means of the connector (24).
The recoil impulse moves the slide (1) backwards. After about 3mm movement to the rear, the
locking action between the barrel (2) and the slide (1) will be released, the barrel swings downwards
over the locking block (22) and is retained in this position. The slide moves back into its final
position on its own. During this return travel the cartridge is pulled out of the barrel by the extractor
(11), and is then thrown out to the right via the ejector (23). The ramp in the slide rails actuates the
connector and separates it from the trigger bar. This causes the trigger bar to be raised by the
trigger spring (25) and to be brought back into the path of the firing pin nose.
3) The recoil spring now brings the slide forwards.
And this happens:
- The trigger bar is pushed onto the safety ramp by the firing pin,
- The firing pin safety is brought onto engagement
- The firing pin is put under partial tension
- A round is passed out of the magazine, and
- The barrel is locked with the slide
The weapon is again secured and ready to fire After the last round has been fired, the slide will
be held in the open position by the slide stop lever (27).
COMPONENT PARTS OF GLOCK PISTOLS
1 Slide
2 Barrel
3 Recoil spring assembly
4 Inapplicable, incorporated in part 3
5 Firing pin
6 Spacer sleeve
7 Firing pin spring
8 Spring cups
9 Firing pin safety
10 Firing pin safety spring
11 Extractor
12 Extractor depressor plunger
13 Extractor depressor plunger spring
14 Spring-loaded bearing
15 Slide cover plate
16 Rear sight
16a Front sight
17 Receiver
18 Magazine catch spring
19 Magazine catch
