60 Qt Mixer Spec Sheet
2153 Dryden Rd., Dayton, OH 45439 | 937-299-5493 | 800-347-5423 | Fax: 937-299-4147 | www.globefoodequip.com
06-2016 Printed in the U.S. © Globe Food Equipment Company Specifications are subject to change without notice.
60 Quart Planetary Floor Mixer SP60
DIMENSIONS | SHIPPING INFORMATION
Reinforced carton for shipping. The weight and dimensions of this reinforced carton are included below and may vary from shipment to shipment.
This product ships on a pallet. Freight class 85.
Model Overall Dimensions Net Weight Shipping Dimensions Shipping Weight
SP60
25.25'' w x 30.5" d x 51.5'' h
(64 cm x 77 cm x 131 cm)
572 lbs
(260 kg)
46'' w x 48" d x 65'' h
(122 cm x 122 cm x 165 cm)
690 lbs
(313 kg)
SPECIFICATIONS
Model Motor Volts Amps
Transmission
Type
Capacity Controls
1st 2nd 3rd 1st 2nd 3rd
SP60 3 HP
220/60/1*
208/60/3*
23
9
Gear 60 qt / 57 liter
Front-mounted digital
controls & timer
73 120 267 49 82 181
Agitator Speeds (RPMs) Attachment Speeds (RPMs)
Cord & Plug: Attached 6-foot exible 3-wire cord with molded plug ts a grounded receptacle. Single phase NEMA L6-30P Three phase NEMA L15-20P
*Specify voltage when ordering.
OPTIONAL MIXER ACCESSORIES AND HUB ATTACHMENTS
MIXER:
o
XXBOWL-60 60 qt stainless steel bowl
o
XXBEAT-60 Alum. flat beater
o
XXBEAT-60SS S/S flat beater
o
XXHOOK-60 Alum. dough hook
o
XXWHIP-60 S/S wire whip
o
XXHDWHIP60-4 Heavy-duty 4 mm
S/S wire whip
o
XXHDWHIP60-5 Heavy-duty 5 mm
S/S wire whip
o
XXSCRP-60 scraper with mounting kit
o
XXACC30-60 Adapter kit - 30 qt
bowl, hook, beater and whip
o
XXACC40-60 Adapter kit - 40 qt
bowl, hook, beater and whip
o
XBTRUCK-60 60 qt heavy-duty
bowl truck
HUB:
o
XVSGH 9" Slicer/Shredder/Grater
housing only (no plates included-must
select from plates listed on this sheet)
o
XASP Adjustable slicing plate (veg. only)
o
XPH Plate holder
Shredding Plates:
o
XSP332* 3/32" (2.3 mm)
o
XSP316* 3/16" (4.7 mm)
o
XSP14* 1/4" (6.3 mm)
o
XSP516* 5/16" (7.9 mm)
o
XSP12* 1/2" (12.7 mm)
o
XGP* Grating plate
*Only 1 plate holder required
o
XMCA-SS Meat grinder sssembly
(Polished stainless steel cylinder, worm
gear, ring, and s/s pan. Includes knife,
3/16" plate, and pusher)
o
XXCK Chopper knife for XMCA-SS
Chopper Plate Sizes Available:
o
CP02-12 1/16" (2 mm)
o
CP04-12 5/32" (4 mm)
o
CP05-12 3/16" (5 mm)
o
CP06-12 1/4" (6 mm)
o
CP08-12 5/16" (8 mm)
o
CP10-12 3/8" (10 mm)
o
CP12-12 1/2" (12 mm)
o
CP14-12 9/16" (14 mm)
o
CP16-12 5/8" (16 mm)
o
CP18-12 11/16" (18 mm)
o
CP00-12 Stuffing plate
o
XST12 1/2" Stuffing tube (mutton)
o
XST34 3/4" Stuffing tube (pork)
o
FACTORY INSTALLED OPTION:
XXCORR-60 Correctional package,
includes tamper resistant external
fasteners.
o
EXTENDED WARRANTY
SP-XD4060 Extended warranty for
SP60 mixer, extends factory warranty
to 2 years. Available only at time
of purchase.
Mixer is constructed of a rigid cast iron body with front-mounted touch pad controls and 60-minute digital timer with last-batch recall. Mixer has
3 HP custom built motor with overload protection and gear-driven, high-torque, permanently lubricated transmission consisting of heat-treated
hardened steel alloy gears and shafts. Mixer comes standard with 60 qt. stainless steel bowl, aluminum flat beater, stainless steel bowl truck and
wire whip, aluminum dough hook and non-slip rubber feet. Interlocked with removable stainless steel bowl guard with fully welded ingredient
chute. Mixer has #12 attachment hub and interlocked bowl lift. Mixer is NSF and ETL listed. Two year parts and one-year labor warranty.
Drawings available through KCL at www.kclcad.com.
51.5 (131)
25.25 (64)
30.5 (77)
