4. Mechanical dimensions
The NFC 3V3 board shows the following mechanical dimensions:
Quota Dimensione MAX
PBC_W 83mm
PCB_L 45mm
PCB_H 1.6mm
Ant_W 40÷60mm (tbd)
Ant_L 40mm
The electronic board has all components on one side only and the connectors must be of type SMT.
Figure 1 NFC 3V3 board mechanical dimensions
