This document and information herein is the property of Global Display Solutions and all unauthorised use and

Unpublished Property of GDS.

MAN10408_00 1 of 8

MAN10408 Rev.00

Description

User Manual - NFC 3V3 board

GDS Part No.

BRD01288 - 0WR00975AA

Issue Date

27.11.2012

Issue Level

Pages

Author(s):

Signature:

Date:

F.Ceccato

27/11/2012

Approved:

P. Giardini

P.Giardini

27/11/2012

Final Release

This technical literature is subject to change without notice.

Please contact GDS or its representative before designing your product based on this specification

Summary of content (8 pages)

PAGE 1
MAN10408 Rev.00 Description User Manual - NFC 3V3 board GDS Part No. BRD01288 - 0WR00975AA Issue Date 27.11.2012 Issue Level 00 Pages 7 Author(s): Signature: Date: F.Ceccato F.Ceccato 27/11/2012 P.Giardini 27/11/2012 Approved: P. Giardini Final Release This technical literature is subject to change without notice.
PAGE 2
TABLE OF CONTENTS 1. 2. 3. 4. 5. 6. 7. FCC Notice (U.S. Only) ............................................................................................................................ 3 Safety Instructions .................................................................................................................................... 4 NFC compatibility .....................................................................................................................................
PAGE 3
1. FCC Notice (U.S. Only) FCC Class B – Applicable only to Limited Feature connections This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instruction manual, may cause interference with radio and television reception. This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. This device complies with Part 15 of the FCC Rules.
PAGE 4
2. Safety Instructions The NFC 3V3 board is a Mifare/NFC reader module of the display NIC-SP (G0700004 - 0WR00874AA). It must be used for no other purpose. Read the Safety Instruction carefully and keep it for use later. Beware of all warning and instruction signs marked on the NFC 3V3 board. Ensure that the ambient temperature around the module is between +5°C and +50 °C (with relative humidity between 5% and 85%). 3.
PAGE 5
4. Mechanical dimensions The NFC 3V3 board shows the following mechanical dimensions: Quota PBC_W Dimensione MAX 83mm PCB_L PCB_H Ant_W 45mm 1.6mm 40÷60mm (tbd) Ant_L 40mm The electronic board has all components on one side only and the connectors must be of type SMT. Figure 1 NFC 3V3 board mechanical dimensions This document and information herein is the property of Global Display Solutions and all unauthorised use and reproduction is prohibited. Copyright © 2012 by Global Display Solutions, Italy.
PAGE 6
5. Connections The NFC 3V3 has the main connector (Picoblade Molex SMT - 53398-087) with reference J9 Pin 1 2 3 4 5 6 7 8 Function +3.3Vdc UART_TX UART_RX NC NC NC NC GND Description Power Supply Serial Data Out Serial Data In RTS out CTS in Relè out NC Ground Figure 2 J9 connector details The NFC 3V3 board is intended to be mounted as a peripheral device to a hostsystem (display NIC-SP G0700004 - 0WR00874AA). The cable connection is supplied on the hostsystem. 6.
PAGE 7
Figure 3 NFC 3V3 board state diagram with and without equipment connected This document and information herein is the property of Global Display Solutions and all unauthorised use and reproduction is prohibited. Copyright © 2012 by Global Display Solutions, Italy. All rights reserved. Confidential, Unpublished Property of GDS.
PAGE 8
7. Labelling The NFC 3V3 board has labeling showing FCC ID code, GDS SpA board code and Technogym SpA codes. Figure 4 NFC 3V3 board labelling Using a permanently affixed label, the modular transmitter is labeled with its own FCC identification number, and, if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module.
