Technical Specifi cations
Connect Devices to a Network with a GC-100
Power Input
•9 to 18V DC@300mA (wall power
adapter included)
•International 220V available
LED indicators
•Power
•Network activity
•Link status
•IR transmission
•Sensor input state
•GC-100 visual ID
Setup
•Integrated web server for easy
confi guration
•Confi gure through TCP/IP set up
commands
Discovery & Setup Utility
•Included Windows-based software
simplifi es GC-100 network discovery
of units and setup
• AMX beacon support
Network Interface
•Connector: RJ45
•Protocol: 10 Base-T Ethernet
•Standards: TCP, DHCP, HTTP
Serial Interface
•Connector: Male DB9
•Data Rates: 1200 baud to 57.6
Kbaud
•Parity: odd, even, none
•Flow control: bi-directional hard-
ware RTS/CTS
•IR input: utilizing a GC-IRE and GC-
RG1, IR commands are received via
RS232 port.
IR & Sensor Interface
•Connector: 3.5mm stereo jack
•Selectable IR outputs or sensor
inputs per port
•IR input: IR commands received
via RS232 port utilizing GC-IRE and
GC-RG1
•IR emitter supplied for each IR port
•GC-BL2 IR Blaster support
Relay Interface
•Connector: screw terminal plug,
24V AC/DC@.5A, N.O. contact with
transient voltage suppression
•Capability: contact closures
Certifi cations
•FCC (Part 15, Class B), C-tick, CE
•RoHs compliant
Software
•Product
GC-IRL Learner Utility
Discovery & Setup Utility
•Development and Testing
GC-100 Test Utility
GC-CCF Conversion Utility
GC-Scan Test Utililty
IR Test Utility
Warranty
•One year limited warranty
•Support available through phone
and email, as well as extensive
online library
GC-100-12
