X299X AORUS MASTER Motherboard Block Diagram
LGA2066 CPU
CPU CLK+/- (100~500 MHz)
1 USB Type-C
™
,
with USB 3.2 Gen 2
support
1 USB Type-C
™
,
with USB 3.2 Gen 2
support
1 USB 3.2
Gen 2 Type A
DDR4 2933
(Note)
/2666/2400/2133 MHz
PCI Express 3.0 Bus
DMI 3.0
LAN2 LAN1
RJ45 RJ45
ASMedia
®
USB 3.2 Gen 2
ASMedia
®
USB 3.2 Gen 2
M.2 WiFi
Module
Intel
®
GbE LAN
Aquantia
5GbE LAN
x1x1
x1 x1
x1
8 SATA 6Gb/s
(SATA3 0~7)
LPC
Bus
SPI
Bus
PCI Express 3.0 Bus
PCI Express 3.0 Bus
Center/Subwoofer
Speaker Out
Line Out
MIC
Line In
S/PDIF Out
Rear Speaker Out
CODEC
+
ESS SABRE9218
TPM
iTE
®
Super I/O
4 USB 2.0/1.1
2 USB 2.0/1.1
8 USB 3.2 Gen 1
USB 2.0
Hub
Intel
®
X299
Dual BIOS
PCI Express x16_1
PCI Express x8_1 PCI Express x8_2
PCI Express x16_2
Switch
x16 x8
x16
1 M.2 Socket 3
(M2M)
1 M.2 Socket 3
(M2Q)
1 M.2 Socket 3
(M2P)
(Note) Actual support may vary by CPU.
2 USB 3.2 Gen 12 USB 2.0/1.1
Realtek
®
USB
3.2 Gen 1 Hub
x1
