& Congured as eSATA
Enables or disables support for external SATA devices.
 PCIE Slot VROC & Bifurcation
& PCIE_16_1 Slot
Allows you to determine how the bandwidth of the PCIEX16_1 slot is divided. Options are: PCIE x16
(default), PCIE 4x4, VROC x4, VROC 4x4.
& PCIE_8_1 Slot
Allows you to determine how the bandwidth of the PCIEX8_1 slot is divided. Options are: PCIE x8 (default),
PCIE 2x4, VROC x4.
& PCIE_16_2 Slot
Allows you to determine how the bandwidth of the PCIEX16_2 slot is divided. Options are: PCIE x16
(default), PCIE 4x4, VROC x4, VROC 4x4.
& PCIE_8_2 Slot
Allows you to determine how the bandwidth of the PCIEX8_2 slot is divided. Options are: PCIE x8 (default),
PCIE 2x4, VROC x4.
& M2M VROC
Allows you to enable or disable VROC support for the M2M connector. (Default: Disabled)
& M2Q VROC
Allows you to enable or disable VROC support for the M2Q connector. (Default: Disabled)
 Network Stack Conguration
& Network Stack
Disables or enables booting from the network to install a GPT format OS, such as installing the OS from
the Windows Deployment Services server. (Default: Disabled)
& Ipv4 PXE Support
 EnablesordisablesIPv4PXESupport.ThisitemiscongurableonlywhenNetwork Stack is enabled.
& Ipv4 HTTP Support
 EnablesordisablesHTTPbootsupportforIPv4.ThisitemiscongurableonlywhenNetwork Stack is
enabled.
& Ipv6 PXE Support
 EnablesordisablesIPv6PXESupport.ThisitemiscongurableonlywhenNetwork Stack is enabled.
& Ipv6 HTTP Support
 EnablesordisablesHTTPbootsupportforIPv6.ThisitemiscongurableonlywhenNetwork Stack is
enabled.
& IPSEC Certicate
 EnablesordisablestheInternetProtocolSecurity.ThisitemiscongurableonlywhenNetwork Stack is
enabled.
& PXE boot wait time
 Allowsyoutocongurehowlongtowaitbeforeyoucanpress<Esc>toabortthePXEboot.Thisitemis
congurableonlywhenNetwork Stack is enabled. (Default: 0)
& Media detect count
 Allowsyoutosetthenumberoftimestocheckthepresenceofmedia.Thisitemiscongurableonlywhen
Network Stack is enabled. (Default: 1)
