Hardware Installation
• M2Q
(Note)
:
SATA3 0 SATA3 1 SATA3 2 SATA3 3 SATA3 4 SATA3 5 SATA3 6 SATA3 7
M.2 PCIe SSD *
a a a a a a a a
No M.2 SSD Installed
a a a a a a a a
a: Available, r: Not available
* The M2Q connector supports only PCIe SSDs.
Connector
Type of
M.2 SSD
• M2M
(Note)
:
SATA3 0 SATA3 1 SATA3 2 SATA3 3 SATA3 4 SATA3 5 SATA3 6 SATA3 7
M.2 PCIe SSD *
a a a a a a a a
No M.2 SSD Installed
a a a a a a a a
a: Available, r: Not available
* The M2M connector supports only PCIe SSDs.
Connector
Type of
M.2 SSD
Installation Notices for the M.2 and SATA Connectors:
The M2P connector shares bandwidth with the SATA3 0 connector. Refer to the following tables for details.
(Note) The M2M and M2Q connectors become unavailable when an Intel
®
Core
™
X series 28-lane processor
is used.
• M2P:
SATA3 0 SATA3 1 SATA3 2 SATA3 3 SATA3 4 SATA3 5 SATA3 6 SATA3 7
M.2 SATA SSD
r
a a a a a a a
M.2 PCIe SSD
a a a a a a a a
No M.2 SSD Installed
a a a a a a a a
a: Available, r: Not available
Connector
Type of
M.2 SSD
