User`s manual

- 4 -
Table of Contents
GA-G41MT-S2 Motherboard Layout ................................................................................5
Chapter 1 Hardware Installation .....................................................................................6
1-1 Installation Precautions .................................................................................... 6
1-2 Product Specications ...................................................................................... 7
1-3 Installing the CPU and CPU Cooler ................................................................. 9
1-3-1 Installing the CPU .....................................................................................................9
1-4 Installing the Memory ..................................................................................... 10
1-4-1 Dual Channel Memory Conguration .....................................................................10
1-5 Installing an Expansion Card ......................................................................... 10
1-6 Back Panel Connectors .................................................................................. 11
1-7 Internal Connectors ........................................................................................ 12
Chapter 2 BIOS Setup ..................................................................................................19
2-1 Startup Screen ............................................................................................... 19
2-2 The Main Menu .............................................................................................. 19
2-3 MB Intelligent Tweaker(M.I.T.) ........................................................................ 20
2-4 Standard CMOS Features .............................................................................. 26
2-5 Advanced BIOS Features .............................................................................. 27
2-6 Advanced Chipset Features ........................................................................... 29
2-7 Integrated Peripherals .................................................................................... 30
2-8 Power Management Setup ............................................................................. 31
2-9 PnP/PCI Congurations ................................................................................. 33
2-10 PC Health Status ............................................................................................ 33
2-11 Load Fail-Safe Defaults .................................................................................. 34
2-12 Load Optimized Defaults ................................................................................ 35
2-13 Set Supervisor/User Password ...................................................................... 35
2-14 Save & Exit Setup .......................................................................................... 36
2-15 Exit Without Saving ........................................................................................ 36
Chapter 3 Drivers Installation ........................................................................................37
3-1 Installing Chipset Drivers ............................................................................... 37
Regulatory Statements ..................................................................................................38
