User`s manual

BIOS Setup - 24 -

: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
x DrivingStrengthProle  Auto
x Data Driving Pull-Up Level Auto
x Cmd Driving Pull-Up Level Auto
x Ctrl Driving Pull-Up Level Auto
x Clk Driving Pull-Up Level Auto
x Data Driving Pull-Down Lev Auto
x Cmd Driving Pull-Down Lev Auto
x Ctrl Driving Pull-Down Lev Auto
x Clk Driving Pull-Down Lev Auto
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
Channel A/B Driving Settings
Item Help
Menu Level

tRD Phase0 Adjustment
Options are: Auto (default), 0-Normal, 1-Advanced.
tRD Phase1 Adjustment
Options are: Auto (default), 0-Normal, 1-Advanced.
tRD Phase2 Adjustment
Options are: Auto (default), 0-Normal, 1-Advanced.
tRD Phase3 Adjustment
Options are: Auto (default), 0-Normal, 1-Advanced.
Trd2rd(Different Rank)
Options are: Auto (default), 1~15.
Twr2wr(Different Rank)
Options are: Auto (default), 1~15.
Twr2rd(Different Rank)
Options are: Auto (default), 1~15.
Trd2wr(Same/Diff Rank)
Options are: Auto (default), 1~15.
DIMM1 Clock Skew Control
Options are: Auto (default), +800ps~-700ps.
DIMM2 Clock Skew Control
Options are: Auto (default), +800ps~-700ps.
DDR Write Leveling
Allows you to determine whether to ne-tune memory parameters to enhance memory compatibility.
Auto Lets the BIOS decide whether to enable this function. (Default)
Enabled Enables this function to enhance memory compatibility.
Disabled Disables this function.
DDR Write Training
Allows you to determine whether to ne-tune memory parameters to enhance memory compatibility.
Auto Lets the BIOS decide whether to enable this function. (Default)
Enabled Enables this function to enhance memory compatibility.
Disabled Disables this function.
Channel A/B Driving Settings
