CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
Advanced Timing Control

: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

x tRRD Auto
x tWTR Auto
x tWR Auto
x tRFC Auto
x tRTP Auto
x Command Rate (CMD) Auto
>>>>> Channel A

Channel A Timing Settings [Press Enter]

Channel A Driving Settings [Press Enter]
>>>>> Channel B

Channel B Timing Settings [Press Enter]

Channel B Driving Settings [Press Enter]
tRRD
Options are: Auto (default), 1~15.
tWTR
Options are: Auto (default), 1~31.
tWR
Options are: Auto (default), 1~31.
tRFC
Options are: Auto (default), 1~255.
tRTP
Options are: Auto (default), 1~15.
Command Rate(CMD)
Options are: Auto (default), 1~3.
>>>>> Channel A/B
Channel A/B Timing Settings
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
Channel A/B Timing Settings

: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

x Static tRead Value Auto
x tRD Phase0 Adjustment Auto
x tRD Phase1 Adjustment Auto
x tRD Phase2 Adjustment Auto
x tRD Phase3 Adjustment Auto
x Trd2rd(Different Rank) Auto
x Twr2wr(Different Rank) Auto
x Twr2rd(Different Rank) Auto
x Trd2wr(Same/Diff Rank) Auto
x DIMM1 Clock Skew Control Auto
x DIMM2 Clock Skew Control Auto
x DDR Write Leveling Auto
x DDR Write Training Auto
Static tRead Value
Options are: Auto (default), 1~15.
